i-Autoc KSV Series Solid State Relay DIN Rail Mount 24V DC Coil 25mA KSV240D30-LM

i-Autoc KSV240D30-LM is a single-phase solid state relay designed for industrial applications requiring reliable and efficient switching. This DIN Rail mounted SSR features an integrated heatsink to enhance thermal management, ensuring long operational life under demanding conditions. It is equipped with a 24V DC coil voltage and operates with a low coil current of 25mA.

This solid state relay supports switching currents up to 30A using SCR output technology, making it suitable for heavy-duty loads. The relay accommodates switching DC voltages of 24V and operates efficiently within a temperature range of -30°C to 80°C. Its PCB terminal type ensures robust electrical connections for secure installation.

The i-Autoc KSV SSR series provides zero crossing switching and accepts both AC and DC control voltages, enhancing versatility across various industrial systems. Additional features include LED indication for operational status and a built-in RC snubber circuit that protects against voltage spikes and extends relay lifespan.

The product's compact dimensions (100 mm length, 112.5 mm height, and 30.5 mm width) facilitate easy integration into panel designs or DIN Rail assemblies compliant with DIN EN50022. This relay is suited for industrial automation, electrical control systems, manufacturing equipment, HVAC controls, and other applications requiring precise and reliable switching.

Designed for DIN Rail mounting with integrated heatsink for efficient heat dissipation. Supports a coil voltage of 24V DC with a coil current of 25mA. Capable of switching currents up to 30A with SCR output technology. Operational temperature range from -30°C to 80°C for reliable performance.

Features PCB terminal for secure electrical connections. Includes LED indication and a built-in RC snubber circuit for protection. Offers zero crossing switching, suitable for AC or DC input variations. Compact dimensions: 100mm length, 112.5mm height, and 30.5mm width.

This i-Autoc Solid State Relay is RoHS compliant and manufactured in China. It combines reliable performance with durability for demanding industrial environments. Explore EnvMart's extensive catalog of industrial relays and electrical components to find compatible devices and accessories.
