MEAN WELL IP67 Rated 1 Output LED Driver, 5V, 30W, 5A Constant Voltage AC-DC Enclosed Panel Mount LED Driver

Free Delivery in India | Lowest Global Shipping Charges

MEAN WELL IP67 Rated 1 Output LED Driver, 5V, 30W, 5A Constant Voltage AC-DC Enclosed Panel Mount LED Driver

Name: MEAN WELL IP67 Rated 1 Output LED Driver, 5V, 30W, 5A Constant Voltage AC-DC Enclosed Panel Mount LED Driver
Brand: MEAN WELL
SKU: 202524



Category LED Lighting Components Brand MEAN WELL Condition New

Specifications

Country of Origin	India
Brand	MEAN WELL
Model	IP67
IP Rating	IP67
Mount Type	Panel
Series	LPV-35
Configuration	Enclosed
Sub Type	LED Driver
Operating Modes	Constant Voltage
Number of outputs	1
Terminal type	Wire
Maximum Output Power	30W
Input Voltage	264, 90V ac
Output Voltage	5V
Power Dissipation	30W
Standards/Approvals	CB, EN, IEC, LPS, UL, CSA, CE
Primary Type	AC-DC
Driver Current	5A
LED Voltage	264, 90V ac

Key Features

Designed with high efficiency and high reliability for long operational life.
Waterproof IP67 rating makes it ideal for outdoor installations and harsh environments.
Supports constant voltage output with over-current, short circuit, and over-voltage protections.
Panel mount with wire terminals and epoxy encapsulation for enhanced durability.
Complies with international standards including CB, EN, IEC, UL, CSA, and CE.
Withstands 300Vac surge input for 5 seconds ensuring robust performance.
Includes 600mm un-terminated input (18AWG) and output (16AWG) leads for flexible wiring.
Meets EMI and harmonic current compliance to EN 55022 and EN 61000 standards.

Product Description

MEAN WELL LPV-35-5 is an industrial-grade IP67 rated LED driver designed for reliable constant voltage LED lighting applications. Operating at 5V output voltage with a maximum power rating of 30W and delivering 5A driver current, it is suitable for both indoor and outdoor installations.

This driver is housed in a rugged enclosed panel mount configuration with epoxy encapsulation, offering robust protection against dust and water ingress conforming to the IP67 standard. It features built-in protections including short circuit, over-current, and over-voltage safeguards, enhancing operational safety and product longevity.

The unit accepts a wide AC input voltage range including 90V to 264V, and withstands surges up to 300Vac for 5 seconds. It is supplied with 600mm un-terminated input and output leads with appropriately gauged wiring for secure and versatile installation.

Certified under multiple global standards such as CB, EN, IEC, UL1310 Class 2, and CSA, this LED driver also complies with stringent EMC and harmonic current regulations. It undergoes a 100% burn-in test at full load assuring quality and reliability for industrial use.

This LED driver series is highly effective in powering LED lighting systems and moving sign applications, making it a dependable choice in commercial, industrial, and outdoor lighting solutions. Power derating applies above 65°C ambient (55°C for the 5V model).

High efficiency and long operational life reliability. Waterproof and dustproof design with IP67 enclosure. Constant voltage output with multiple safety protections. Wide input voltage range with surge resistance. Panel mount style with robust wire terminals.

Conforms to global safety and EMC standards. Tested for full-load operational durability. Application suited for LED lighting and signage. Ideal for industrial, commercial, and outdoor environments. UL1310 Class 2 power unit classification.
