Relpol PCB Power Relay, 220V AC Coil, 40A Switching Current, 1 CO, Silver Alloy Contacts R40N-3011-85-5220

Free Delivery in India | Lowest Global Shipping Charges

Relpol PCB Power Relay, 220V AC Coil, 40A Switching Current, 1 CO, Silver Alloy Contacts R40N-3011-85-5220

Name: Relpol PCB Power Relay, 220V AC Coil, 40A Switching Current, 1 CO, Silver Alloy Contacts R40N-3011-85-5220
Brand: Relpol
SKU: 202398
Price: 18.75 USD
Availability: InStock



Category Power Relay Brand Relpol Condition New

Specifications

Country of Origin	Poland
Brand	Relpol
Height	20.5mm
Length	32.5mm
Model	R40N-3011-85-5220
Width	25.5mm
Mount Type	PCB
Contact Material	Silver Alloy
Series	R40N
Maximum Operating Temperature	100°C
Contact Configuration	1 CO
Minimum Operating Temperature	-55°C
Switching Current	40A
Terminal type	PCB Pin
Contact Resistance	30mΩ
Standards/Approvals	EAC, RoHS
Coil Resistance	13.5kΩ
Coil Voltage	220V ac
Switching DC Voltage	110V dc
Switching AC Voltage	110V ac
Coil Power	2W

Key Features

Designed for PCB mounting with PCB pin terminals for secure installation.
Built with silver alloy contact material ensuring low contact resistance of 30 milliohms.
Operates efficiently from -55°C to 100°C, suitable for industrial environments.
Compact dimensions of 32.5mm length, 25.5mm width, and 20.5mm height.
Low coil power consumption at 2 watts enhances energy efficiency.
Supports switching power up to 9.6 kVA for handling high electrical loads.
Coil resistance fixed at 13.5 kilo-ohms for stable coil operation.
Complies with EAC and RoHS standards ensuring quality and safety.

Product Description

Relpol R40N-3011-85-5220 PCB Power Relay is a high-performance industrial relay designed for general-purpose applications requiring reliable switching. Featuring a coil voltage of 220V AC and capable of handling 40A switching current, this relay is ideal for automation, machine control, and electronic equipment.

The relay's 1 CO contact configuration uses silver alloy material that offers a contact resistance of only 30 milliohms, ensuring efficient electrical conduction and durability. It supports switching both AC and DC voltages up to 110V. The coil power consumption is low at 2W, making this relay energy efficient for prolonged use.

Measuring 32.5mm in length, 25.5mm in width, and 20.5mm in height, the relay is compact and designed for PCB mounting using pin terminals, facilitating easy and reliable installation on printed circuit boards.

This relay is rated to operate reliably across a temperature range from -55°C to 100°C, making it suitable for applications exposed to harsh or variable industrial conditions. It supports a maximum switching power of 9.6 kVA, allowing it to handle significant electrical loads.

The R40N series from Relpol complies with EAC and RoHS standards, underscoring its quality, reliability, and environmental compliance. The coil resistance is specified at 13.5 kilo-ohms, contributing to stable relay operation.

Designed for PCB mounting with PCB pin terminals for secure installation. Silver alloy contacts provide low resistance and high durability. Wide operating temperature range from -55°C to 100°C. Compact foot-print suitable for space-constrained environments.

Supports switching power up to 9.6 kVA and current up to 40A. Low coil power consumption enhances efficiency. Approved to EAC and RoHS standards.

This PCB power relay is widely used in industrial automation, electronic control systems, manufacturing equipment, and automotive electronics for reliable switching performance. The compact design and robust specifications make it ideal for integration in complex assemblies requiring high load switching capabilities.
