Relpol PCB Power Relay, 48V DC Coil, 8A Switching Current, DPDT RM84-2012-35-1048

Free Delivery in India | Lowest Global Shipping Charges

Relpol PCB Power Relay, 48V DC Coil, 8A Switching Current, DPDT RM84-2012-35-1048

Name: Relpol PCB Power Relay, 48V DC Coil, 8A Switching Current, DPDT RM84-2012-35-1048
Brand: Relpol
SKU: 202390
Price: 4.37 USD
Availability: InStock



Category Power Relay Brand Relpol Condition New

Specifications

Country of Origin	Poland
Brand	Relpol
Height	15.7mm
Length	29mm
Model	RM84-2012-35-1048
Width	12.7mm
Mount Type	PCB
Contact Material	Silver Alloy
Series	RM84
Maximum Operating Temperature	85°C
Contact Configuration	DPDT
Minimum Operating Temperature	-40°C
Switching Current	8A
Terminal type	PCB Pin
Contact Resistance	100mΩ
Standards/Approvals	RoHS, EAC
Coil Resistance	5.7kΩ
Coil Voltage	48V dc
Switching DC Voltage	24V dc
Switching AC Voltage	440V
Coil Power	480mW

Key Features

This miniature industrial relay is part of the RM84 series for general purpose use.
Features a coil voltage of 48V DC with coil power of 480mW and resistance of 5.7kΩ.
Contact configuration is Double Pole Double Throw (DPDT) using silver alloy contacts.
Switching capacity includes 8A current, 2kVA power, 24V DC and 440V AC switching voltages.
Compact dimensions of 29mm length, 12.7mm width, and 15.7mm height enable easy PCB integration.
Operate reliably in temperatures ranging from -40°C to 85°C.
Certified to RoHS and EAC standards, ensuring environmental compliance.
Contact resistance is low at 100mΩ, supporting efficient electrical conduction.

Product Description

Relpol RM84-2012-35-1048 PCB Power Relay features a 48V DC coil and supports an 8A switching current with DPDT contact configuration, making it ideal for various industrial and electronic applications requiring reliable relay switching on printed circuit boards.

This miniature relay belongs to the RM84 series, known for compact dimensions and versatility in control applications where space and performance are critical. The relay coil consumes 480mW power with 5.7kΩ coil resistance, optimized for efficient operation.

The relay switches power up to 2kVA with a switching DC voltage of 24V and AC voltage of 440V, suitable for switching both AC and DC loads. Contacts are made of silver alloy, providing low contact resistance of 100mΩ for effective conductivity and durability.

Mechanical design includes a mounting type for PCB with PCB pin terminals, ensuring easy installation on printed circuit boards. The relay operates efficiently across a wide temperature range from -40°C to 85°C, supporting harsh industrial environments.

The product complies with RoHS and EAC standards, confirming environmental safety and reliability. This miniature power relay is designed for compact, general-purpose industrial applications. Supports 48V DC coil voltage and 8A switching current for robust relay performance.

DPDT contact configuration offers versatile switching options. Low contact resistance and silver alloy contacts enhance conductivity and lifespan. PCB mounting with pin terminals for seamless circuit integration. Wide operating temperature range enables use in diverse conditions.

Certified to RoHS and EAC standards for compliance and sustainability.

Relpol power relays are essential components in electronics, automation, manufacturing, HVAC control systems, and industrial machinery for switching electrical loads safely and effectively.
