Panasonic PCB Power Relay 24V DC Coil 10A Switching Current SPDT ALQ1F24

Panasonic ALQ1F24 PCB Power Relay is a high-performance component designed for PCB mounting with a 24V DC coil and capability to switch 10A current through SPDT contacts.

This compact power relay measures 20mm in length, 10mm in width, and 15.6mm in height, making it suitable for space-constrained applications in various industries including household appliances, industrial machinery, robotics, and lighting equipment.

Operating efficiently at ambient temperatures from -40°C to +85°C, it supports high surge voltage tolerance of 8000 V and breakdown voltage of 4000 V, delivering exceptional robustness under demanding conditions.

The silver alloy contacts combined with low contact resistance (100 mΩ) ensure reliable electrical connectivity and switching performance with switching power capabilities up to 30W, at switching voltages of 250V AC and 30V DC.

The coil's electrical characteristics include a resistance of 1.4 kΩ and power consumption of 400 mW, designed for energy-efficient switching operations. Compliant with RoHS and VDE certifications, the ALQ1F24 relay aligns with industry standards for safety and environmental regulations.

Typical industrial use cases include refrigerator controls, cooking ovens, washing machines, air conditioning systems, motor control panels, and robotic automation, emphasizing its versatile applications across residential and industrial automation sectors.

The relay features SPDT contact configuration suitable for versatile switching applications. Compact dimensions of 20mm length, 10mm width, and 15.6mm height make it ideal for PCB mounting. Operates within a wide ambient temperature range of -40°C to +85°C, ensuring durability in various environments.

Coil resistance of 1.4 kΩ with coil power of 400 mW enables efficient operation with low power consumption. High switching capacities include 30W power, 250V AC, and 30V DC switching voltages. Contacts are made of silver alloy with low contact resistance of 100 mΩ for reliable conduction.

Meets RoHS and VDE standards enhancing environmental compliance and safety. Applications include appliances, industrial equipment, motor control, robotics, and power supply systems. Explore the complete range of Power Relays and electrical components for advanced automation and control solutions at EnvMart.
