Vishay Multilayer Ceramic Capacitor 330 pF 100V dc ±5 % Tolerance Surface Mount 0603 Case VJ Series VJ0603A331JXBAC

Free Delivery in India | Lowest Global Shipping Charges

Vishay Multilayer Ceramic Capacitor 330 pF 100V dc ±5 % Tolerance Surface Mount 0603 Case VJ Series VJ0603A331JXBAC

Name: Vishay Multilayer Ceramic Capacitor 330 pF 100V dc ±5 % Tolerance Surface Mount 0603 Case VJ Series VJ0603A331JXBAC
Brand: Vishay
SKU: 201815
Price: 0.06 USD
Availability: InStock



Category Multilayer Ceramic Capacitor Brand Vishay Condition New

Specifications

Country of Origin	India
Voltage	100V dc
Brand	Vishay
Height	0.94mm
Length	1.6mm
Model	VJ0603A331JXBAC
Packaging	7 in Reel/Paper Tape
Width	0.8mm
Mount Type	Surface
Series	VJ
Termination Type	Surface Mount
Maximum Operating Temperature	150°C
Tolerance	±5 %
Capacitance	330pF
Minimum Operating Temperature	-55°C
Standards/Approvals	RoHS, JEDEC JS709A, IEC 61249-2-21
Package/Case	0603
Dielectric	C0G

Key Features

Provides stable capacitance with C0G (NP0) dielectric for ultra-low temperature coefficient.
0603 case size with compact dimensions of 1.6mm length, 0.8mm width, and 0.94mm height.
Suitable for surge suppression, decoupling, and filtering in electronic circuits.
Operates reliably across a temperature range from -55°C to 150°C.
RoHS compliant and meets JEDEC JS709A and IEC 61249-2-21 standards.
Utilizes a reliable Noble Metal Electrode (NME) construction for durability.
Packaged in 7-inch reel with paper tape suitable for automated assembly.

Product Description

Vishay VJ0603A331JXBAC is a high-quality multilayer ceramic chip capacitor designed for surface mount technology applications. It features a capacitance of 330 pF and a voltage rating of 100V dc, with a ±5 % tolerance that ensures precision in various industrial and commercial electronic circuits.

The capacitor uses a C0G (NP0) dielectric, known for its ultra-stable temperature characteristics and low dissipation factor, making it ideal for timing, tuning, and filtering applications where minimal capacitance drift is critical.

With a compact 0603 case size measuring 1.6 mm in length, 0.8 mm in width, and 0.94 mm in height, this component supports high-density PCB layouts. It operates efficiently within a wide temperature range from -55°C up to 150°C, suitable for harsh industrial environments.

The Vishay VJ series capacitor includes features such as surge suppression and exceptional aging stability, making it suitable for use in automotive, industrial, medical, and consumer electronics. The noble metal electrode (NME) construction ensures reliable performance over the product lifespan.

This capacitor is RoHS compliant and adheres to industry standards including JEDEC JS709A and IEC 61249-2-21, ensuring compatibility with global quality requirements. Stable capacitance with C0G (NP0) dielectric. Compact 0603 footprint for space-saving designs.

Wide operating temperature range from -55°C to 150°C. Suitable for decoupling, filtering, surge suppression, timing, and tuning circuits. RoHS compliant with JEDEC and IEC approvals. NME system for long-term reliability.

Delivered on 7-inch reel with paper tape packaging for automated insertion machines.

This multilayer ceramic capacitor is essential for enhancing circuit stability and reliability across electronic manufacturing sectors, including industrial automation, telecommunications, consumer electronics, and automotive systems.
