HARWIN M22 Series Straight Through Hole Pin Header 24 Contacts 2 mm Pitch 2 Row Unshrouded M22-2021205
Specifications
| Country of Origin | India |
|---|---|
| Brand | HARWIN |
| Orientation | Straight |
| Current | 1A |
| Model | M22-2021205 |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Phosphor Bronze |
| Series | M22 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 24 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 3.4mm |
| Mating Pin Length | 3.5mm |
Key Features
- Supports a current rating of 1 amp for reliable electrical performance.
- Constructed with a nylon housing material that withstands high temperatures during soldering.
- Gold-plated phosphor bronze contacts ensure excellent conductivity and corrosion resistance.
- Features a tail pin length of 3.4 mm and mating pin length of 3.5 mm for secure connections.
- Designed for through-hole mounting with straight orientation and male contact gender.
- Operates within a temperature range from -40°C up to a maximum of 105°C.
- The unshrouded design offers flexibility for PCB board-to-board connectivity.
- Suitable for embedded PCs, motherboards, and large electronics systems requiring compact pin headers.
Product Description
HARWIN M22-2021205 is a high-quality M22 series straight through hole pin header connector designed for board-to-board PCB connections. This component features 24 gold-plated phosphor bronze contacts arranged in 2 rows with a 2 mm pitch, supporting up to 1 amp of current. The housing is made from durable nylon material capable of withstanding high reflow soldering temperatures, making it suitable for modern manufacturing processes.
The connector's unshrouded, straight orientation and male contact gender provide versatile usage in compact electronic assemblies. Tail pin lengths of 3.4 mm and mating pin lengths of 3.5 mm ensure reliable and stable connections. Operating temperature ranges from -40°C to +105°C enable this pin header to perform in diverse industrial and commercial electronics applications.
Ideal for embedded PCs, consumer electronics, communications equipment, drives and controls, industrial monitoring, and personal computing devices. The M22 series supports various configurations and is established as a standard in the electronics manufacturing industry.
Supports a current rating of 1 amp for reliable electrical performance. Constructed with a nylon housing material that withstands high temperatures during soldering. Gold-plated phosphor bronze contacts ensure excellent conductivity and corrosion resistance.
Features a tail pin length of 3.4 mm and mating pin length of 3.5 mm for secure connections. Designed for through-hole mounting with straight orientation and male contact gender. Operates within a temperature range from -40°C up to a maximum of 105°C.
The unshrouded design offers flexibility for PCB board-to-board connectivity. Suitable for embedded PCs, motherboards, and large electronics systems requiring compact pin headers. Explore the Electronics Components category on EnvMart for a comprehensive range of PCB connectors and headers to support your electronic design and manufacturing needs.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a current rating of 1 amp, ensuring reliable electrical performance.
The pitch size is 2 mm, allowing for compact connections in electronic assemblies.
The housing is made from nylon, and the contacts are gold-plated phosphor bronze, which provides excellent conductivity and corrosion resistance.
It operates within a temperature range from -40°C to a maximum of 105°C.
This pin header features 24 contacts arranged in 2 rows.
It is designed for through-hole mounting, facilitating secure installation on PCBs.
The tail pin length is 3.4 mm, ensuring a secure connection.
The mating pin length is 3.5 mm, which contributes to stable connections.
It has a male contact gender, suitable for various electronic applications.
This model is unshrouded, offering flexibility for board-to-board connectivity.
It uses solder termination, which is common for reliable electrical connections in PCB applications.
It is suitable for embedded PCs, motherboards, and large electronics systems requiring compact pin headers.
