Cosel High Efficiency PCB Mount DC/DC Converter 30V Output -30V Output, 500mA, 24V-18V Input, 15W, DIP Package MGW152415-R
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | Converters / DC-DC Converters Cosel MGW DC/DC Converter, 30V dc, -30 V dc/ 500 m |
| Brand | Cosel |
| Efficiency | 89% |
| Length | 25.4mm |
| Model | MGW152415-R |
| Depth | 9.9mm |
| Gross Weight | 20g |
| Width | 9.9mm |
| Mount Type | PCB |
| Series | MGW |
| Maximum Operating Temperature | 85°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 2 |
| Ripple and Noise | 150mV Pk-Pk |
| Maximum Output Power | 15W |
| Maximum Input Voltage | 24V dc |
| Standards/Approvals | CE, cUL, cULus, EN 60950-1, TUV, UL 60950-1 |
| Minimum Input Voltage | 18V |
| Number of Pins | 6 |
| Output Voltage 1 | 30, -30V dc |
| Output Current 1 | 500mA |
| Output Voltage Adjustment Range | 14.602 to 15.505 V |
| Isolation Voltage | 1.5kV dc |
| Output Current 2 | 0.5A |
| High reliability | no built-in aluminium and tantalum electrolytic capacitor |
Key Features
- Provides a maximum output power of 15 watts for efficient power conversion.
- Features a ripple and noise of 150mV peak-to-peak for stable performance.
- Supports wide operating temperature range from -40°C to 85°C.
- Designed for PCB mounting with a SIP6/DIP package and 6 pins for easy integration.
- Includes built-in overvoltage and overcurrent protection with 1.5kV DC isolation voltage.
- High reliability with no aluminium or tantalum electrolytic capacitors and 89% efficiency.
- Certified with CE, cUL, cULus, EN 60950-1, and TUV standards.
- Compact dimensions measuring 25.4mm length by 9.9mm width and depth with a lightweight of 20 grams.
Product Description
Cosel MGW152415-R PCB mount DC/DC converter delivers two isolated outputs of 30V and -30V DC with 500mA current capacity, powered by an input voltage range between 18V and 24V DC. This high-efficiency (89%) converter supports continuous maximum output power of 15W, making it ideal for industrial, electronic component, and power supply applications requiring compact size and high reliability.
The converter comes with a rugged DIP package and SIP6 pin configuration, allowing easy PCB integration. It operates reliably within the broad temperature range of -40°C to 85°C, suitable for demanding environments. The device provides 1.5kV DC isolation for enhanced safety, built-in overvoltage and overcurrent protection circuits, and a remote On/Off function to control operation remotely.
The design excludes aluminium or tantalum electrolytic capacitors for increased product longevity. This unit meets stringent safety and quality standards including CE, UL, cUL, EN 60950-1, and TUV approvals. Typical applications include power management in instrumentation, telecommunications, and industrial control systems.
Provides maximum output power of 15 watts with 89% efficiency. Wide input voltage range from 18V to 24V DC supports various power environments. Dual output voltages (30V and -30V) for versatile power applications. Reliable PCB mounting with DIP package and 6 pins for easy assembly.
Operating temperature range of -40°C to 85°C ensures robust performance. Offers 1.5kV isolation voltage and built-in protection circuits. Certified to multiple international safety standards for industrial use. Lightweight design of 20g and compact dimensions 25.4mm x 9.9mm x 9.9mm.
This Cosel MGW Series DC/DC converter combines industry-standard mounting, a powerful feature set, and high reliability for use in laboratory, industrial manufacturing, electronics manufacturing, and commercial power equipment. Browse the category to explore additional DC/DC Converters suitable for your power supply requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output power of this model is 15 watts.
It supports an input voltage range between 18V and 24V DC.
This unit provides dual output voltages of 30V and -30V DC.
It has an efficiency rating of 89%.
The ripple and noise is specified at 150mV peak-to-peak.
The operating temperature range is from -40°C to 85°C.
This model has two outputs.
It uses a DIP package for PCB mounting.
It is certified with CE, cUL, cULus, EN 60950-1, and TUV standards.
The isolation voltage is rated at 1.5kV DC.
The weight of this model is 20 grams.
It features a 6-pin configuration for easy integration.
