Cosel DC/DC Converter, 5V DC Output, 3 A, 24V DC Input, 15 W, PCB Mount, 6-Pin DIP MGFS152405-R

Cosel MGFS152405-R DC/DC Converter delivers a regulated 5V DC output at 3 A, powered from input voltages between 9V and 24V DC. This PCB-mountable converter uses a 6-pin DIP package with compact dimensions (25.4 mm x 9.9 mm x 9.9 mm) and has a maximum output power rating of 15 Watts.

Designed for industrial and commercial power supply applications, this converter features an 88% efficiency using a synchronized rectification circuit to reduce power loss and heat generation. It supports reliable operation over a wide ambient temperature range from -40°C to +85°C, suitable for harsh environments.

The converter offers a 500V DC isolation voltage for operator safety and signal integrity. It includes integrated overcurrent and overvoltage protection circuits to safeguard the device and connected equipment. The ripple and noise output is maintained at 150mV peak-to-peak, ensuring clean power delivery for sensitive electronics.

This model is part of the MGFS series, which comes with an On/Off remote function for flexible control. The product achieves high reliability by eliminating aluminium and tantalum electrolytic capacitors from its construction.

Compliance with rigorous international standards such as TUV, CE, cUL, cULus, EN 60950-1, and UL 60950-1 confirms its safety and quality credentials. Its lightweight design, weighing only 20 grams, makes it ideal for dense PCB layouts in industrial, manufacturing, communication, and instrumentation applications.

Operates with input voltage ranging from 9V to 24V DC. Offers a high efficiency of 88% with synchronized rectification circuit. Features built-in overcurrent and overvoltage protection circuits. Compact dimensions: 25.4 mm length, 9.9 mm width, and 9.9 mm depth.

Durable operation in temperature range of -40°C to 85°C. Provides 500V DC isolation voltage to ensure safety and reliability. Includes ripple and noise level of 150mV peak-to-peak. Complies with multiple international standards including TUV, CE, cUL, and UL 60950-1.

Designed without aluminium or tantalum electrolytic capacitors for enhanced reliability. Includes On/Off remote function as part of the MGFS series features.

This Cosel MGFS152405-R DC/DC Converter is an excellent choice for stable, isolated DC power conversion in demanding industrial, laboratory, HVAC, manufacturing, and electronic equipment applications. EnvMart offers this high-quality converter designed in Japan for long-lasting and efficient performance in a compact SIP6 form factor.
