TRACOPOWER DIMENSION Switched Mode DIN Rail Power Supply 1-Phase 240V AC Input 28V DC, 5A Output, 120W CS5.241
Specifications
| Country of Origin | China |
|---|---|
| Brand | TRACOPOWER |
| Power | 120W |
| Height | 124mm |
| Model | CS5.241 |
| Depth | 117mm |
| IP Rating | IP20 |
| Width | 32mm |
| Series | DIMENSION |
| Output Current | 5A |
| Maximum Operating Temperature | 70°C |
| Sub Type | Switched Mode |
| Minimum Operating Temperature | -25°C |
| Number of outputs | 1 |
| Maximum Input Voltage | 240V ac |
| Electrical Phase | 1 |
| Maximum Output Voltage | 28V dc |
| Minimum Input Voltage | 100V ac |
Key Features
- The power supply features a wide input voltage range from 100V to 240V AC for global compatibility.
- It delivers high efficiency up to 90.2%, reducing energy consumption and heat generation.
- Designed for durability, it operates reliably between -25°C and 70°C ambient temperatures.
- The unit has a compact form factor with 124mm height, 32mm width, and 117mm depth, saving DIN rail space.
- Equipped with IP20 protection rating, it is suitable for controlled indoor environments.
- The product includes auto voltage input selection and minimal inrush current for stable operation.
- Its construction supports industrial control, automation, and communication equipment applications.
- Complies with IEC and UL standards, ensuring safety and quality assurances.
Product Description
PULS CS5.241 Switched Mode DIN Rail Power Supply is a robust single-phase device designed for industrial, automation, and communication systems requiring stable DC output.
This power supply supports a wide input voltage range of 100V to 240V AC and delivers 28V DC output at a current of 5A, with a rated power of 120W. Its slim DIMENSION series form factor (124mm H x 32mm W x 117mm D) facilitates easy installation into control panels and DIN rails with limited space.
Featuring high efficiency up to 90.2%, the CS5.241 reduces operational energy loss and heat dissipation, enhancing longevity and reliability. It is engineered for operation in temperatures ranging from -25°C to 70°C, enabling stable performance in diverse industrial environments.
The power supply incorporates auto voltage selection, minimal inrush current, and an IP20 rating for protection against solid objects, making it suitable for indoor electrical enclosures. It does not offer hazardous area certification but meets IEC and UL safety standards.
Its applications include industrial control systems, automation machinery, instrumentation, and communication equipment requiring steady 28V DC power. The power supply features a wide input voltage range from 100V to 240V AC for global compatibility.
It delivers high efficiency up to 90.2%, reducing energy consumption and heat generation. Designed for durability, it operates reliably between -25°C and 70°C ambient temperatures. The unit has a compact form factor with 124mm height, 32mm width, and 117mm depth, saving DIN rail space.
Equipped with IP20 protection rating, it is suitable for controlled indoor environments. The product includes auto voltage input selection and minimal inrush current for stable operation. Its construction supports industrial control, automation, and communication equipment applications.
Complies with IEC and UL standards, ensuring safety and quality assurances.
This PULS DIN Rail Power Supply CS5.241 is manufactured in China and offered in new condition. It is ideal for industrial machines, laboratory instruments, HVAC control panels, and manufacturing automation systems. For reliable and efficient DIN rail power solutions, explore more offerings in the Power Supplies category on EnvMart.
Explore more products in our DIN Rail Power Supplies category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a wide input voltage range from 100V to 240V AC, making it suitable for global compatibility.
The unit has a compact form factor with dimensions of 124mm height, 32mm width, and 117mm depth.
It features high efficiency up to 90.2%, which helps reduce energy consumption and heat generation.
The power supply operates reliably in ambient temperatures ranging from -25°C to 70°C.
It has an IP20 protection rating, suitable for controlled indoor environments.
This power supply features one output.
It is designed for industrial control systems, automation machinery, instrumentation, and communication equipment.
It includes auto voltage input selection for stable operation.
It is a switched mode power supply, which is designed for efficiency and performance.
This model is manufactured in China.
It complies with IEC and UL safety standards, ensuring quality assurances.
