Cosel DC/DC Converter 12V dc Output 2.5A, 36-48V dc Input, 30W Power, PCB Mount, 6-Pin DIP MGS304812-R

Cosel MGS304812-R DC/DC Converter is a high-quality electronic component designed for efficient power conversion and electrical isolation. It outputs 12V DC at 2.5A from a wide input voltage range of 36 - 48V DC, with a continuous power output of 30 watts.

This converter is mounted on a PCB and comes in a 6-pin DIP package, measuring 25.4 mm by 9.9 mm by 9.9 mm and weighing 40 grams. It features a compact 1-inch square footprint, making it ideal for space-constrained electronic applications.

Engineered with a synchronised rectification circuit, it achieves a high efficiency of 92%, reducing energy loss and heat generation. The device includes a built-in remote ON/OFF function for easy power control and overcurrent protection that automatically recovers, ensuring durability and safety.

The output voltage can be externally adjusted within ±10%, allowing fine tuning to meet specific system requirements. With an isolation voltage of 1.5kV AC, this DC/DC Converter ensures reliable electrical isolation between input and output circuits, critical for sensitive electronics.

It operates reliably within a temperature range from -40°C to 85°C, suitable for demanding industrial and commercial environments. The design omits aluminium and tantalum electrolytic capacitors to enhance long-term reliability and lifespan.

Certified to meet cULus, TUV, CE, and UL 60950-1 standards, this converter complies with international safety and performance requirements. Made in Japan, it is ideal for industrial, laboratory, and commercial power supply applications where compact size, efficiency, and reliability are essential.

Industry standard 1 inch by 1 inch footprint suitable for PCB mounting. High efficiency of 92% achieved via synchronised rectification circuit. Built-in remote ON/OFF control for enhanced operational flexibility. 6-pin DIP package with 1.5kV AC isolation voltage ensuring robust electrical isolation.

Supports output voltage adjustment ±10% via external variable resistor. Protected against overcurrent with automatic recovery functionality. Operates reliably across -40°C to 85°C temperature range. High reliability with no built-in aluminium or tantalum electrolytic capacitors.

Compact form factor: length 25.4mm, width 9.9mm, depth 9.9mm and weighs 40 grams. Conforms to multiple standards including cULus, TUV, CE, and UL 60950-1. Explore our comprehensive range of power converters and electronic components at EnvMart for reliable industrial power management solutions.
