Cosel DC/DC Converter 12V dc 2.5A 36V dc Input 9V Input 30W PCB 6-Pin DIP MGFS302412-R

The Cosel MGFS302412-R DC/DC Converter is an industrial-grade voltage conversion module designed for robust applications requiring 12V dc output with currents up to 2.5A. It accepts a wide input voltage range from 9V up to 36V dc, making it versatile for various power sources and challenging environments. Packaged in a 6-Pin DIP form factor for PCB integration, this converter operates efficiently with an impressive 89% efficiency rating, enabled by synchronized rectification circuitry.

Its compact dimensions (25.4mm length × 50.8mm width × 9.9mm depth) and lightweight construction (40 grams) make it ideal for embedded electronics and power supply designs where space and weight are constrained. The unit offers an isolation voltage of 500V dc, providing essential electrical isolation for sensitive circuitry, enhancing safety and noise suppression.

Engineered without aluminium or tantalum electrolytic capacitors, the MGFS302412-R promises high reliability and longevity, suitable for demanding industrial, electronics manufacturing, telecom, and embedded applications. It features built-in overcurrent protection circuits that automatically reset and overvoltage protection, ensuring the converter operates safely without user intervention.

Rated for operation from -40°C up to +85°C, this converter suits harsh environmental conditions, including outdoor and industrial environments exposed to temperature extremes. The PCB mountable DIP package enables straightforward integration into custom printed circuit boards for power management.

Additional advantages include an on/off remote function for external control and adherence to industrial SIP6 standards. The product is manufactured in Japan, ensuring stringent quality control and build standards. The MGFS series from Cosel provides a comprehensive solution for isolated DC voltage conversion with low noise and high efficiency, meeting stringent industrial requirements.

Wide input range DC 9 - 36 V dc for flexible power supply options. High efficiency with synchronized rectification circuit reduces power loss. Built-in overcurrent and overvoltage protections with automatic recovery enhances operational reliability.

Compact 6-Pin DIP package for easy PCB mounting in compact assemblies. Operating temperature range from -40°C to 85°C allows for harsh environment use. Isolation voltage of 500V dc for electrical safety and noise immunity.

High reliability design without aluminium and tantalum electrolytic capacitors. Manufactured in Japan, ensuring consistent high quality and reliability. Suitable for diverse industrial, telecom, medical, and embedded electronics applications.
