Myrra 15 V 5 Output PCB Transformer, VDC, RoHS, ENEC, UL, CE, 3W 48025
Specifications
| Country of Origin | China |
|---|---|
| Brand | Myrra |
| Power | 3W |
| Efficiency | 72% |
| Length | 25mm |
| Model | 48025 |
| Depth | 16mm |
| Gross Weight | 16g |
| Width | 25mm |
| Mount Type | PCB |
| Maximum Operating Temperature | 80°C |
| Minimum Operating Temperature | -25°C |
| Number of outputs | 5 |
| Output Range | 3.3VDC - 24VDC |
| Input Range | 85VAC - 265VAC/47 - 63Hz Or 120VDC - 370VDC |
| Materials | Plastic And Resin |
| Standards/Approvals | VDC, RoHS, ENEC, UL, CE |
| Primary Voltage | 240 V ac, 340 V dc |
| Secondary Voltage | 15 V |
| Minimum Operating Frequency | 47Hz |
| Maximum Operating Frequency | 63Hz |
| Encapsulated Design And Same Footprint As 20 Transformer | Upgrade Your Application Without Redesign Of PCB |
Key Features
- Compact dimensions of 25mm length, 25mm width, and 16mm depth fit small PCB designs.
- Encapsulated design with plastic and resin materials ensures durability and electrical insulation.
- Low standby power consumption under 0.15W enhances energy efficiency.
- Certified to RoHS, ENEC, UL, and CE standards ensuring compliance and safety.
- Operating temperature range from -25°C minimum up to 80°C maximum for varied environments.
- 72% efficiency rating supports effective power conversion.
- Single output with primary side regulation for stable output voltage.
- Lightweight design at 16 grams suitable for compact electronic assemblies.
Product Description
The Myrra 48025 PCB Transformer is a 3W power component designed for compact PCB mounting applications where a regulated 15 V secondary output is required across 5 outputs. It features a robust encapsulated design made from high-quality plastic and resin materials, ensuring high durability and protection against environmental factors.
This transformer supports a broad input voltage range, including 85VAC to 265VAC at 47-63Hz and DC input range of 120VDC to 370VDC, making it versatile for various power supply configurations. The output voltage range from 3.3VDC to 24VDC and a single output with primary side regulation provide stable and reliable power performance for electronic devices.
With compact dimensions of 25mm length, 25mm width, and 16mm depth, this unit is optimized for installation in space-constrained electronics. It maintains an impressive 72% energy efficiency and achieves very low standby power consumption below 0.15W, contributing to reduced energy waste.
Designed to operate in harsh conditions, the transformer is rated for a minimum operating temperature of -25°C and maximum temperature up to 80°C, suitable for industrial, electronic manufacturing, and power supply applications.
The product complies with international standards including RoHS, ENEC, UL, and CE certifications, ensuring adherence to strict safety and environmental guidelines. Compact size and PCB mount capability. Wide input voltage and frequency range.
Low standby power consumption below 0.15W. Construction with plastic and resin materials. Certified to multiple global safety and environmental standards.
This Myrra PCB Transformer is ideal for power supply units, industrial control electronics, communication equipment, and laboratory power designs requiring compact reliable power conversion. Its encapsulated construction and efficient performance make it a dependable choice for modern electronics manufacturing.
Discover more products in our Electronics & Electricals catalog and browse additional PCB Transformer models to find the optimal power solution for your application.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a power rating of 3W, making it suitable for compact PCB applications requiring regulated output.
The Myrra 48025 has an efficiency rating of 72%, supporting effective power conversion.
It has compact dimensions of 25mm in length, 25mm in width, and 16mm in depth, optimized for space-constrained installations.
The operating temperature range for the Myrra 48025 is from -25°C to 80°C, allowing it to function in varied environments.
This unit supports an input voltage range of 85VAC to 265VAC at 47-63Hz or 120VDC to 370VDC, making it versatile for different power supply configurations.
The transformer provides an output voltage range from 3.3VDC to 24VDC across its five outputs.
It features an encapsulated design made from plastic and resin materials, ensuring durability and electrical insulation.
This transformer is certified to RoHS, ENEC, UL, and CE standards, ensuring compliance with safety and environmental guidelines.
The Myrra 48025 weighs 16 grams, making it lightweight and suitable for compact electronic assemblies.
This model features primary side regulation, which helps maintain a stable output voltage across its outputs.
It has a low standby power consumption of under 0.15W, enhancing energy efficiency.
The Myrra 48025 is designed for PCB mounting, making it suitable for various electronic applications.
