binder Miniature Circular Connector, Panel Mount Socket, Female, 3 Contacts, 250V, 7A, IP40, 678 Series 99.0608.00.03
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 250V |
| Brand | binder |
| Orientation | Straight |
| Current | 7A |
| IP Rating | IP40 |
| Mount Type | Panel Mount |
| Housing Material | Polyamide |
| Contact Material | Brass |
| Series | 678 |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Contact Plating | Silver |
| Number of Contacts | 3 |
| Contact Gender | Female |
| Shell Size | 19 mm |
| Mating Type | Bayonet |
| Connector Size | Miniature |
| Plug/Socket | Socket |
Key Features
- This connector features a bayonet mating type ensuring secure and reliable connections.
- Constructed with a polyamide housing and brass contacts plated in silver for durability and conductivity.
- Designed for flange-mounting on panels with a shell size of 19 mm and overall diameter of 20 mm.
- Operates reliably within a temperature range of -40°C to 85°C, suitable for varied environmental conditions.
- The socket is female gender with solder termination providing ease of assembly and maintenance.
- Designed to IP40 standard, protecting against solid objects larger than 1 mm but not protected against liquids.
- Applications include industrial equipment, electronic components, and power and connector systems.
Product Description
binder 99.0608.00.03 Miniature Circular Connector Socket is a high-quality panel mount industrial circular connector designed for electronic and power applications. It features 3 female contacts rated at 7A and 250V, ensuring reliable current and voltage performance. The connector utilizes a bayonet mating type for swift and secure connections.
The connector housing is made from durable polyamide material, providing mechanical strength and resistance to environmental factors. Contacts are brass plated with silver to optimize conductivity and corrosion resistance. Its flange-mounting design facilitates easy panel integration.
With a shell size of 19 mm and an overall diameter of 20 mm, this miniature connector fits compact installations. It is rated IP40 for protection against solid foreign objects larger than 1 mm, making it suitable for indoor industrial environments.
The unit performs optimally across a temperature range of -40°C to 85°C, accommodating various operating conditions. Solder termination type allows stable electrical connections to cables or circuit boards.
This model belongs to binder's 678 Series of connectors, well-known for quality and precision in industrial circular connectors. This connector features a bayonet mating type ensuring secure and reliable connections. Constructed with a polyamide housing and brass contacts plated in silver for durability and conductivity.
Designed for flange-mounting on panels with a shell size of 19 mm and overall diameter of 20 mm. Operates reliably within a temperature range of -40°C to 85°C, suitable for varied environmental conditions. The socket is female gender with solder termination providing ease of assembly and maintenance.
Designed to IP40 standard, protecting against solid objects larger than 1 mm but not protected against liquids. Applications include industrial equipment, electronic components, and power and connector systems.
This binder circular connector is ideal for industrial, manufacturing, electronic equipment, power connectors, and control panel applications requiring dependable electrical connections. Explore more in EnvMart's Industrial Circular Connector category for systems and accessories.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The connector is rated for a voltage of 250V.
It has a current rating of 7A.
This connector is designed to an IP40 rating, which protects against solid objects larger than 1 mm but does not protect against liquids.
The housing is made of polyamide, and the contacts are brass plated with silver for improved conductivity.
It operates reliably within a temperature range of -40°C to 85°C.
This model features 3 female contacts.
The connector uses a solder termination type, allowing for stable electrical connections.
The shell size is 19 mm, with an overall diameter of 20 mm.
It features a bayonet mating type for secure and reliable connections.
No, it is rated IP40, which means it is not protected against liquids and is intended for indoor industrial environments.
This connector is designed for panel mounting.
It is suitable for applications in industrial equipment, electronic components, and power and connector systems.
