KEMET R82 Metallised Polyester Film Capacitor 6.8nF 100V DC 63V AC Radial Lead Through Hole R82EC1680Z350K

KEMET R82EC1680Z350K film capacitor is a high-quality metallised polyester film capacitor with a capacitance of 6.8 nF and tolerance of ±10%. This radial lead through hole capacitor is designed for robust electrical performance at rated DC voltage of 100 V and AC voltage of 63 V. It is suitable for commercial, automotive, and industrial electronic applications including blocking, coupling, decoupling, timing, and oscillator circuits.

The capacitor features radial leads made of tinned wire with a lead pitch of 5 mm and lead length of 17 mm, enhancing solderability and mechanical stability. Its encapsulation in a self-extinguishing, solvent-resistant plastic case ensures safety and durability in demanding environments.

With operating temperature capability ranging from -55°C to +105°C, the capacitor supports reliability across varied climatic conditions. Compliance with IEC 60384-2 and RoHS directives underlines its adherence to international quality and environmental standards. The product also meets the automotive AEC-Q100 standard, confirming suitability for automotive electronics systems.

The compact Z3 package case measures approximately 7.2 mm in length, 6.5 mm in height, and 2.5 mm in width, making it ideal for space-constrained PCB layouts. This KEMET capacitor offers dependable performance for electronic engineers and designers developing circuits requiring stable capacitance and high voltage tolerance.

Capacitance value is 6.8 nanofarads with ±10% tolerance. Rated for 100 V DC and 63 V AC voltage applications. Features through hole radial lead mount type with tinned wire leads. Operating temperature range from -55°C to +105°C ensures stability.

Meets IEC 60384-2, RoHS compliance, and automotive AEC-Q100 standards. Encapsulated in a self-extinguishing, solvent resistant plastic case. Compact Z3 package case dimensions: Length 7.2 mm, Height 6.5 mm, Width 2.5 mm.

Lead pitch of 5 mm with 0.6 mm lead diameter and 17 mm lead length. Pin count of 2 suitable for through-hole PCB mounting. Manufactured in Indonesia with assured quality standards.

This film capacitor is ideal for use in industrial, automotive, and consumer electronic circuits requiring precise capacitance and reliable voltage handling. Explore more Film Capacitors and electronic components on EnvMart for your design and manufacturing needs.
