3M 3000 Series Right Angle Through Hole PCB Header, 14 Contacts, 2.54 mm Pitch, 2 Row, Shrouded N3314-5202RB

Free Delivery in India | Lowest Global Shipping Charges

3M 3000 Series Right Angle Through Hole PCB Header, 14 Contacts, 2.54 mm Pitch, 2 Row, Shrouded N3314-5202RB



Category PCB Connectors & Wire Housings Brand 3M Condition New

Specifications

Country of Origin	United States
Voltage	1V
Brand	3M
Orientation	Right Angle
Current	1.75
Model	N3314-5202RB
Mount Type	Through Hole
Housing Material	Glass Filled Polyester
Contact Material	Copper Alloy
Series	3000
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	14
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Board-to-Board, Wire-to-Board
Tail Pin Length	0.01in
Mating Pin Length	6.2mm
Connector,PCB,multipole,header,solder,r/a,short,14way,HE10Brand	3M

Key Features

Features 14 male contacts arranged in two rows for stable connections.
Constructed with glass filled polyester housing for durability.
Shrouded design prevents accidental contact and short circuits.
Gold plated copper alloy contacts offer excellent conductivity and corrosion resistance.
Solder termination ensures strong mechanical and electrical bonding.
Suitable for board-to-board and wire-to-board applications.
Operates reliably between -55°C and 105°C temperature range.
Rated for 1.75 A current and 1 V voltage applications.

Product Description

3M N3314-5202RB 3000 Series Right Angle Through Hole PCB Header is engineered for efficient and secure electronic board connections, featuring a 2.54 mm pitch and 14 male contacts in two rows. This shrouded header is designed for through-hole mounting, delivering reliable performance in diverse industrial and electronic environments.

The connector housing is made from glass filled polyester providing robustness and high insulation. The contacts are composed of copper alloy with gold plating, ensuring excellent electrical conductivity and resistance to corrosion, critical for long-term electronic circuit stability.

This solder termination type connector offers a strong physical and electrical bond to PCBs, ideal for applications requiring mechanical stress resistance and stable signal transmission. Its shrouded design enhances safety by preventing accidental contact and potential short circuits during assembly or maintenance.

Designed for a broad range of uses, including automation systems, electronic circuit boards, electrical assemblies, automotive electronics, and various mechanical devices demanding secure through-hole installation.

The connector supports operation in temperatures from -55°C up to 105°C, and sustains up to 1.75 A current and 1 V voltage, suitable for both low and moderate power applications. Manufactured in the United States, it meets quality and reliability standards demanded in industry.

Features 14 male contacts arranged in two rows for stable connections. Constructed with glass filled polyester housing for durability. Shrouded design prevents accidental contact and short circuits. Gold plated copper alloy contacts offer excellent conductivity and corrosion resistance.

Solder termination ensures strong mechanical and electrical bonding. Suitable for board-to-board and wire-to-board applications. Operates reliably between -55°C and 105°C temperature range. Rated for 1.75 A current and 1 V voltage applications.

Manufactured in the United States ensuring quality standards.

This 3M PCB Header is a trusted choice for industrial, electronic manufacturing, automotive, and automation applications. Discover more premium PCB connectors and electronic components in the Electronics & Electricals category at EnvMart.
