Glenair 9 Way Right Angle 1.91 mm Pitch Through Hole Micro-D Male D-Sub Connector GMR7590

The Glenair GMR7590 is a 9 Way Right Angle Through Hole Micro-D Male D-Sub Connector featuring a 1.91 mm pitch, known for its high density and compact size. The connector offers reliable electrical performance with gold over nickel plated copper alloy contacts, providing excellent conductivity and corrosion resistance. Its housing is manufactured from liquid crystal polymer, contributing to mechanical durability and thermal stability across operating ranges from -55°C to 150°C.

This connector is designed specifically for right angle PCB mounting with solder termination, making it suitable for high-reliability electronic applications in industrial, aerospace, and telecommunications sectors. The Micro-D connector design allows for a 23-43% reduction in PCB space and a 12-20% weight reduction compared to standard connectors, enabling more compact electronic assemblies.

The connector’s 3 amp current rating supports moderate power electronic needs, and the precision machined nickel-plated shell housing ensures a secure mating interface with trapezoidal polarization to prevent incorrect connections. Interfacial sealing gaskets are fitted as standard for environmental protection in operational environments.

The GMR7590 series does not come with additional standards or approvals but maintains RoHS compliance, meeting environmental safety regulations. Manufactured in the United Kingdom, it reflects stringent quality controls and material traceability.

Compact 9 contact Micro-D design maximizes PCB density. Right angle orientation supports space-saving PCB layouts. Gold plated copper alloy contacts offer high conductivity. Operating temperature range suitable for harsh industrial environments.

Liquid crystal polymer housing ensures mechanical and thermal resilience. Solder termination ensures strong and reliable electrical connections. Interfacial sealing gaskets provide environmental protection. Ninety-degree PCB mounting reduces wiring complexity and space.

Suitable for industrial, aerospace, and telecommunication electronics. Explore more high-quality D-Sub Connectors from Glenair and related power and signal connector solutions on EnvMart for advanced electronic component needs.
