Kingbright Red Surface Mount LED 0603 Package 2.4 V Forward Voltage 100mA Forward Current KPG-0603SURC-TT
Specifications
| Country of Origin | China |
|---|---|
| Brand | Kingbright |
| Model | KPG-0603SURC-TT |
| Packaging | Tape & Reel |
| Mount Type | Surface |
| Series | KPG-0603 |
| Maximum forward current | 100mA |
| Viewing angle | 140 ° |
| Package Type | 0603 |
| Standards/Approvals | RoHS |
| LED Colour | Red |
| Dominant Wavelength | 631nm |
| Forward Voltage | 2.4V |
| Number of Pins | 2 |
| LED Luminosity | 35 mcd |
| Maximum Power Dissipation | 48mW |
| Lens Dimensions | 0.65 x 0.35 x 0.2 mm |
| Lens Shape | Rectangular |
Key Features
- The LED features a viewing angle of 140 degrees for wide visibility.
- It has a package dimension of 0.65 x 0.35 x 0.2 mm with a rectangular clear lens.
- This LED offers luminous intensity of 35 millicandela (mcd) with a dominant wavelength of 631 nm.
- The component is RoHS compliant and supplied in tape and reel packaging for efficient assembly.
- It is intended for use in backlight and indicator applications requiring low power consumption.
- The LED has two pins and is designed for surface mounting on PCBs.
- Manufactured in China, this LED series supports a variety of colour options in the standard 0201 package.
- Packaging on tape and reel supports mass automated PCB assembly.
Product Description
Kingbright KPG-0603SURC-TT is a red LED designed for surface mounting, packaged in the industry-standard 0603 (also known as 0201) size. Rated for a forward voltage of 2.4 V and supporting a maximum forward current of 100 mA, this chip LED provides efficient light emission suitable for numerous electronic applications.
Its compact dimensions of 0.65 x 0.35 x 0.2 mm with a rectangular clear lens ensure it fits in space-constrained circuit designs. The device offers a wide viewing angle of 140 degrees, enhancing visibility in indicator and backlighting roles.
Featuring a luminous intensity of 35 mcd and a dominant wavelength of 631 nm, the LED emits bright red light with excellent clarity. It is RoHS compliant, reflecting adherence to environmental and safety standards.
The product is supplied in tape and reel packaging to facilitate high-volume automated assembly processes, improving production efficiency. With two connection pins, it is suitable for surface mount technology on printed circuit boards.
Kingbright's KPG-0603 series is known for low power consumption and reliable performance. Manufactured in China, this device is ideal for industrial, consumer electronics, instrumentation, and automotive indicator lighting applications.
The LED features a wide 140° viewing angle for broad light distribution. Compact 0.65 x 0.35 x 0.2 mm package size fits tight PCB layouts. Clear rectangular lens enhances light output and color consistency. RoHS compliant for environmentally conscious design requirements.
Packaging on tape and reel supports mass automated PCB assembly. Two-pin surface mount device for easy PCB integration. High luminous intensity of 35 mcd for clear indicators and displays. Dominant wavelength of 631 nm produces vivid red light emission.
This LED component is suitable for use in electronic manufacturing, displays, instrumentation panels, automotive lighting, and other applications where compact and reliable red LEDs are required. Kingbright products offer consistent quality and performance for professional industrial and electronic solutions.
Explore the extensive range of LED components and optoelectronics at EnvMart for your next electronics design or manufacturing project.
Explore more products in our LED - Light Emitting Diodes category.
