MEAN WELL Medical Switching Power Supply 12V DC, 140W, 11.7A, Panel Mount RPS-200-12

MEAN WELL RPS-200-12 switching power supply is a compact medical grade power supply delivering 12V DC output at 140W power and 11.7A output current. Its panel mount form factor with dimensions 101.6mm length, 29mm width, and 29mm depth enables versatile integration in medical and industrial equipment.

Designed with medical safety standards including 2 x MOPP isolation, this power supply is ideal for BF rated patient contact applications such as oral irrigators, hemodialysis machines, medical monitors, sleep apnea devices, pumps machines, and electric beds.

This power supply supports universal AC input voltage from 80V AC to 264V AC and DC input up to 370V, making it suitable for global use. Its 93% efficiency ensures minimal heat generation and energy consumption.

Advanced protections against short circuit, overload, over voltage, and over temperature enhance system safety and reliability. The device features low leakage current and low no-load power consumption to comply with stringent medical requirements.

It operates reliably in temperatures ranging from -30°C to +70°C and employs free air convection cooling for noiseless operation, with an optional 10CFM forced air cooling for higher loads.

The unit includes a power-on LED indicator for status monitoring. The RPS-200-12 series conforms to standards such as ANSI/AAMI ES60601-1, TUV EN60601-1, IEC60601-1, EMC EN55011, BS EN/EN 62368-1, and UL 62368-1.

This makes it ideal for medical, laboratory, industrial, and commercial applications requiring reliable, safety-certified DC power supply. Explore more power supply solutions and industrial electronics on EnvMart. Compact panel mount design measuring 101.6 x 29 x 29 mm for easy installation.

High efficiency of 93% ensures low power loss and heat generation. Universal AC input voltage range from 80V AC to 264V AC and 370V DC maximum input voltage. Medical safety certifications with 2 x MOPP isolation for patient contact use.

Protection features for short circuit, overload, over voltage, and over temperature. Wide operating temperature from -30°C to 70°C. Low leakage current and low no-load power consumption for energy efficiency. Free air convection cooling and optional forced air cooling with 10CFM.

Power on LED indicator for operational status.
