Eaton DOL Starter 3 Phase 110V AC 11 kW IP55 Surface Mount 22A 278333 SDAINLM22(110V50HZ,120V60HZ)

Free Delivery in India | Lowest Global Shipping Charges

Eaton DOL Starter 3 Phase 110V AC 11 kW IP55 Surface Mount 22A 278333 SDAINLM22(110V50HZ,120V60HZ)

Name: Eaton DOL Starter 3 Phase 110V AC 11 kW IP55 Surface Mount 22A 278333 SDAINLM22(110V50HZ,120V60HZ)
Brand: Eaton
SKU: 195126
Price: 648.57 USD
Availability: InStock



Category Motor Starters Brand Eaton Condition New

Specifications

Country of Origin	India
Brand	Eaton
Model	278333 SDAINLM22(110V50HZ,120V60HZ)
IP Rating	IP55
Mount Type	Surface
Overall Length	68mm
Current Rating	22A
Series	SDAINL
Overall Width	158mm
Power Rating	11kW
Note	FLC figures quoted are maximum. The overload specified has been determined by applying the following formula: 0.58 x motor FLC. Allow additional clearance dimensions for the wiring bar above and below the starter
Sub Type	DOL
Number of Phases	3
Maximum Voltage	110V ac
Number of Poles	3
Standards/Approvals	EN/IEC
Overall Depth	125.2mm

Key Features

Rated for a maximum voltage of 110V AC suitable for various industrial power supplies.
Features a current rating of 22A supporting medium-sized motor operations.
Constructed with 3 poles and designed for efficient direct online motor starting.
Compliance with EN/IEC standards ensures reliability and safety in motor control applications.
Compact dimensions of 68mm length, 158mm width, and 125.2mm depth allow easy integration into electrical panels.
Supports motors with efficiency class IE3, optimizing energy consumption.
Equipped with IP55 protection enables resistance against dust and water jets for harsh environments.
Operating temperature range from -25 to +40°C suitable for diverse industrial settings.

Product Description

Eaton 278333 SDAINLM22(110V50HZ,120V60HZ) DOL Starter is a direct online starter designed for three-phase motors, rated at 11 kW with 110V AC supply. It provides robust motor control with an IP55 protection rating for dust and water resistance, ideal for demanding industrial environments.

This starter features a current rating of 22A and is constructed with three poles, enabling efficient and reliable motor starting. It is suitable for surface mounting, facilitating straightforward installation in custom electrical enclosures or control panels.

The device complies with EN/IEC standards, ensuring high safety and operational quality. The compact construction of 68mm length, 158mm width, and 125.2mm depth makes it adaptable to various panel designs while supporting motors with IE3 efficiency classification.

Its operating temperature range from -25°C to +40°C allows use in a wide range of industrial settings. Please note that the overload relay is not included and must be purchased separately to provide motor overload protection.

The starter is made from durable components aligned with the latest IEC 947 standards and is pre-wired to accept Eaton's Z00 or ZB thermal overloads, offering single phasing sensitivity to IEC 947-4. It is configured for surface mounting and direct DIN rail installation.

Rated for 110V AC and 11 kW power rating. Three-phase DOL motor starter with 22A current rating. IP55 protection suitable for dusty and wet industrial conditions. Surface mount type with compact dimensions for flexible installation.

Complies with international EN/IEC standards for safety and performance. Supports efficient motor operation with IE3 class motors. Operating temperature from -25 to +40°C. Designed for use with Eaton Z00 or ZB thermal overload relays.

Overload relay sold separately, must be ordered to complete setup.

This Eaton DOL Starter is essential for industrial, manufacturing, HVAC, and automation applications requiring precise motor start control and protection. Explore the range of Eaton Motor Starters for enhanced motor management solutions at EnvMart.
