XP Power JCA Series DC/DC Converter 5V DC Output, 1A, 18-36V DC Input, 5W Through Hole DIP Package JCA0624S05
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / DC-DC Converters XP Power JCA DC/DC Converter, 5V dc/ 1 A, 36V dc I |
| Brand | XP Power |
| Efficiency | 82% |
| Length | 25.4mm |
| Model | JCA0624S05 |
| Depth | 10mm |
| Width | 20.3mm |
| Mount Type | Through Hole |
| Series | JCA |
| Maximum Operating Temperature | 100°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| MTBF | 1000000h |
| Number of outputs | 1 |
| Maximum Output Power | 5W |
| Maximum Input Voltage | 36V dc |
| Minimum Input Voltage | 18V |
| Number of Pins | 24 |
| Output Voltage 1 | 5V dc |
| Output Current 1 | 1A |
| Isolation Voltage | 1.5kV dc |
| Input Ratio | 2:1 |
| Input Ratio2 | 1 |
Key Features
- This converter features a compact 25.4mm length, 20.3mm width, and 10mm depth DIP metal package.
- Designed with isolation voltage of 1500 VDC from input to output for enhanced safety.
- It operates efficiently at approximately 82% and can function from -40°C up to 100°C ambient temperatures.
- The unit includes 24 pins for through hole mounting on PCBs, following industry standard pinouts.
- It has a mean time between failure (MTBF) rated at 1,000,000 hours for high reliability applications.
- Suitable for industrial, electronic power supply, telecommunications, and embedded system applications.
- Manufactured in Taiwan, Province of China, this converter meets UL and TUV approval standards for quality assurance.
Product Description
XP Power JCA0624S05 is a DC/DC Converter designed for robust and efficient power conversion needs. It provides a regulated 5V DC output with a current capacity of 1A and maximum power of 5W, ideal for powering sensitive electronic circuits in various industrial and commercial applications.
The unit supports an input voltage range from 18V to 36V DC, making it compatible with multiple power supply environments. Its compact DIP package with dimensions 25.4mm (L) x 20.3mm (W) x 10mm (D) allows through hole mounting, facilitating easy integration on PCBs in electronic assemblies.
Featuring a maximum operating temperature of 100°C and a minimum of -40°C, this converter provides reliable performance even in demanding thermal conditions. It also offers high isolation voltage of 1500 VDC between input and output circuits, ensuring operational safety in sensitive equipment installations.
The efficiency rating of 82% helps reduce thermal losses and improves energy savings. The product carries an MTBF of 1,000,000 hours, signifying long-term dependable operation. The series is well suited for telecommunications, power supply systems, instrumentation, and embedded computing devices.
This JCA series DC/DC converter from XP Power is UL and TUV approved, complying with international safety and quality standards. It leverages industry-standard pinouts for ease of design compatibility and offers single output configuration for streamlined power requirements.
Compact and reliable 5W DC/DC isolated converter. Wide 18 - 36V input voltage range with 2:1 input ratio. High isolation voltage of 1500 VDC input to output with basic insulation. Operating temperature range from -40°C to +100°C for harsh environments.
Through hole DIP package with 24 pins suitable for PCB mounting. High efficiency at 82% minimizes energy wastage. MTBF rating of 1,000,000 hours ensures long service life. Manufactured in Taiwan, Province Of China with UL and TUV approvals.
XP Power DC/DC Converters are commonly employed in industrial equipment, telecommunications infrastructure, electronic instrumentation, and embedded system designs requiring isolated and regulated power supply units. Explore EnvMart’s comprehensive selection of DC/DC Converters for reliable power conversion solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports an input voltage range from 18V to 36V DC.
It provides a regulated output of 5V DC with a current capacity of 1A.
The efficiency of this converter is rated at approximately 82%.
This unit has dimensions of 25.4mm in length, 20.3mm in width, and 10mm in depth.
The maximum operating temperature is 100°C, while the minimum is -40°C.
It includes 24 pins for through hole mounting on PCBs.
It features a high isolation voltage of 1500 VDC between input and output circuits.
This converter is suitable for industrial applications, telecommunications, electronic power supply, and embedded systems.
The MTBF is rated at 1,000,000 hours, indicating high reliability.
It comes in a compact DIP package, designed for through hole mounting.
This converter meets UL and TUV approval standards for quality assurance.
The maximum output power is 5W.
