Nexperia 1.24 V Zener Diode Single 250mW 5% Surface Mount 3-Pin SOT-23 BZX84-C24,215

Free Delivery in India | Lowest Global Shipping Charges

Nexperia 1.24 V Zener Diode Single 250mW 5% Surface Mount 3-Pin SOT-23 BZX84-C24,215

Name: Nexperia 1.24 V Zener Diode Single 250mW 5% Surface Mount 3-Pin SOT-23 BZX84-C24,215
Brand: Nexperia
SKU: 189582
Price: 0.04 USD
Availability: InStock



Category Zener Diodes Brand Nexperia Condition New

Specifications

Country of Origin	China
Brand	Nexperia
Height	1.1mm
Length	3mm
Model	BZX84-C24,215
Mount Type	Surface
Series	BZX84
Maximum Operating Temperature	150°C
Package Type	SOT-23
Minimum Operating Temperature	-65°C
Pin Count	3
Number of Elements per Chip	1
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	250mW
Diode Configuration	Single
Test Current It	5mA
Maximum Reverse Leakage Current	50nA
Nominal Zener Voltage Vz	24V
Zener Type	Voltage Regulator
Maximum Zener Impedance	70Ω
Typical Voltage Temperature Coefficient	20.4mV/°C
onsemi 1, 24 V Zener Diode, Single 300 mW 5 % Surface 3-Pin SOT-23Brand	onsemi

Key Features

Designed with a 3-pin SOT-23 package for compact surface mounting.
Maximum power dissipation rating of 250 milliwatts ensures moderate power handling.
Operation temperature range from -65°C to 150°C supports diverse industrial and automotive environments.
Zener voltage tolerance is ±5%, suitable for voltage regulation applications.
Features a low maximum reverse leakage current of 50 nanoamperes.
Typical voltage temperature coefficient of 20.4 mV/°C to preserve regulation accuracy.
Tests at 5 mA test current to validate voltage characteristics.
Complies with automotive standard AEC-Q101 ensuring reliability in automotive electronics.

Product Description

Nexperia BZX84-C24,215 is a high-quality Zener Diode designed for voltage regulation in electronic circuits. This single element diode provides a stable nominal Zener voltage of 24 V with ±5% tolerance. Packaged in a compact SOT-23 3-pin surface mount format, it is ideal for applications demanding small form factors and reliable performance.

The diode supports a maximum power dissipation of 250 mW and can operate efficiently over a wide temperature range from -65°C to 150°C, making it suitable for industrial, automotive, and electronic power supply applications. Its maximum reverse leakage current is as low as 50 nA, contributing to minimal power loss and noise in sensitive circuits.

The device's typical voltage temperature coefficient is 20.4 mV/°C, helping maintain voltage precision under temperature variations. The BZX84 series meets the stringent AEC-Q101 automotive standard, reflecting its robust quality and reliability needed for automotive and other demanding environments.

This zener diode is commonly used for voltage regulation, voltage reference, and protection in power supplies, industrial control systems, measurement instrumentation, and automotive electronics.

Designed with a 3-pin SOT-23 package for compact surface mounting. Maximum power dissipation rating of 250 milliwatts for effective voltage regulation. Operating temperature range from -65°C to 150°C ensures broad application usage.

Voltage tolerance of ±5% supports stable voltage control. Low reverse leakage current of 50 nanoamperes minimizes unwanted current flow. Typical voltage temperature coefficient of 20.4 mV/°C for accuracy in varying temperatures.

Meets AEC-Q101 automotive standard ensuring durability and reliability. Set contains a single BZX84-C24,215 Zener diode packaged ready for surface mount assembly. Explore more electronic components and semiconductors in EnvMart’s comprehensive category.

Explore more products in our Zener Diodes category.
