STMicroelectronics 2 kB Serial EEPROM, 900 ns 8-Pin TSSOP Serial-I2C M24C02-RDW6TP

STMicroelectronics M24C02-RDW6TP is a 2 kB Serial Electrically Erasable PROM (EEPROM) designed for use in various electronics and semiconductor applications. It supports a Serial-I2C interface operating at a maximum clock frequency of 400 kHz, enabling efficient communication for embedded systems and microcontroller interfacing. Packaged in an 8-pin TSSOP, it is well-suited for surface mounting in compact electronic assemblies.

This EEPROM offers an organization of 256 x 8 bits, yielding 256 words of memory, each 8 bits wide. It supports supply voltage ranging from 1.8 V to 5.5 V, making it compatible with a wide range of system voltages. The device features a fast maximum random access time of 900 ns, enabling quick data retrieval and updates.

Capable of operating between temperatures of -40°C and 85°C, the M24C02-RDW6TP meets demanding industrial and automotive environmental requirements. The component complies with the AEC-Q100 automotive standard, ensuring reliability and performance in automotive electronics.

With a data retention capability of up to 200 years, this serial EEPROM guarantees long-term storage of critical data. Its low supply current of 3 mA aids in developing energy-efficient applications.

Physical dimensions of the device are compact, measuring 3.1 mm in length, 1.69 mm in width, and 1.2 mm in height, facilitating its integration into space-constrained circuit boards.

This product is ideal for industrial, automotive, laboratory, telecommunications, and embedded system applications requiring reliable, non-volatile memory with I2C serial communications. The small form factor and robust electrical characteristics enable seamless use in a broad spectrum of electronic systems.

Compatible with all I2C bus interface modes. Operates with supply voltage range from 1.8V to 5.5V. Maximum clock frequency of 400 kHz ensures fast data transfer. Designed for surface mount applications in an 8-pin TSSOP package.

Robust industrial temperature range from -40°C to 85°C operational capability. Data retention of 200 years ensures long-term reliability. Supply current of 3 mA supports low power consumption applications. Automotive grade compliant with AEC-Q100 standard.

Organized memory structure of 256 x 8 bit with 256 words. Compact dimensions with 3.1 mm length, 1.69 mm width, and 1.2 mm height. Explore more semiconductor memory solutions in EnvMart's Electronics & Electricals category.
