MaxLinear Line Transceiver Differential 8-Pin SOIC SP485EN-L/TR
Specifications
| Country of Origin | India |
|---|---|
| Brand | MaxLinear |
| Height | 1.75mm |
| Length | 4.9mm |
| Model | SP485EN-L/TR |
| Width | 3.9mm |
| Mount Type | Surface |
| Output type | Differential |
| Series | SP485 |
| Input Type | Differential |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| IC Type | Line Transceiver IC |
| Number Of Channels | 1 |
| Pin Count | 8 |
| Maximum Supply Voltage | 5.25V |
| Logic Family | BiCMOS |
| Logic Function | Line Transceiver |
| Minimum Supply Voltage | 4.75V |
| Maximum Propagation Delay Time @ CL | 60ns |
| Supply Current | 900μA |
Key Features
- Operates with a supply voltage range of 4.75V to 5.25V ensuring compatibility with standard logic levels.
- Features a single channel differential input and output for reliable data transmission.
- Compact SOIC package with 8 pins suitable for surface mounting.
- Designed for operating temperatures from -40°C to 85°C, suitable for industrial applications.
- Offers a maximum propagation delay time of 60ns at specified load capacitance for fast data transitions.
- Low supply current consumption of 900μA ensures power-efficient operation.
- Complies with RS-485 line driver/receiver standards for robust communication over long cable lengths.
- Non-automotive standard device designed for general industrial and communication uses.
Product Description
MaxLinear SP485EN-L/TR is a differential line transceiver IC packaged in an 8-pin SOIC suitable for surface mount technology. It utilizes BiCMOS logic family providing efficient RS-485 and RS-422 communication capabilities essential for industrial, commercial, and telecommunications equipment.
This line interface IC operates from 4.75V to 5.25V supply voltage and maintains reliable performance across a wide temperature range, from -40°C to 85°C. Its 900μA supply current ensures low power consumption, beneficial in battery-powered or energy-sensitive systems.
The device provides a maximum propagation delay time of 60ns, enabling fast and accurate signal transmission. Its compact dimensions of 4.9mm length, 3.9mm width, and 1.75mm height provide ease of integration into space-constrained PCB designs.
MaxLinear’s SP485 series are known for compatibility with industry standards, making them ideal for data communication over long cables in industrial automation systems, instrumentation, HVAC controllers, and building automation networks.
Operates with a supply voltage between 4.75V and 5.25V supporting standard logic circuits. Single channel differential input and output improve noise immunity in data lines. Compact SOIC 8-pin package designed for surface mount applications.
Wide operation temperature range from -40°C to 85°C meets harsh environment requirements. Low supply current of 900μA ensures efficient power use. Transmission delay time is 60ns at specified load capacitance for high-speed data handling.
Physical dimensions allow tight board layouts, easing design constraints. Conforms to RS-485 standards ensuring industry compatibility and robustness. Designed for general industrial applications but not certified for automotive standards.
This product is new and originates in India. Explore more semiconductor and line transceiver ICs at EnvMart to meet your electronic component needs.
