Murata Wirewound Surface Mount Inductor Non-Magnetic Core 0.82μH ±5% 180mA 2015 Package LQW2BASR82J00L
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Murata |
| Height | 1.42mm |
| Length | 2.09mm |
| Model | LQW2BASR82J00L |
| Depth | 1.53mm |
| Packaging | Embossed Tape |
| Series | LQW |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Non-Magnetic Core |
| Inductance | 0.82μH |
| Standards/Approvals | RoHS |
| Package/Case | 2015 |
| Maximum DC Current | 180mA |
| Maximum DC Resistance | 2.35Ω |
| Inductance Tolerance | ±5 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 230MHz |
| Minimum Quality Factor | 23 |
| Inductor Construction | Wirewound |
Key Features
- Constructed with a wirewound design for enhanced performance.
- Compact 2015 package size with dimensions of 2.09mm length, 1.53mm depth, and 1.42mm height.
- Supports a maximum DC current of 180mA with low DC resistance of 2.35Ω.
- Operating temperature range from -55°C to 125°C suitable for diverse environments.
- High quality factor of minimum 23 ensures efficient filtering and choke applications.
- Non-magnetic core material reduces magnetic interference.
- RoHS compliant and packaged in embossed tape for automated assembly.
- Max self-resonant frequency of 230MHz accommodates high-frequency designs.
Product Description
Murata LQW2BASR82J00L is a wirewound surface mount inductor featuring a non-magnetic core with an inductance of 0.82μH and a tolerance of ±5% designed for high performance in compact electronic circuits.
Its 2015 surface mount package measures 2.09mm in length, 1.53mm in depth, and 1.42mm in height, making it suitable for modern miniaturized designs. The inductor supports a maximum DC current rating of 180mA and maintains low DC resistance of 2.35Ω to minimize power loss.
The operating temperature range from -55°C to 125°C allows usage in automotive, industrial, and consumer electronics with varying thermal conditions. With a minimum quality factor (Q) of 23 and a maximum self-resonant frequency of 230MHz, it is optimized for RF filter and choke applications.
The non-magnetic core material significantly reduces magnetic interference, enhancing signal integrity in sensitive circuits. This component is molded and RoHS compliant, and it is supplied in embossed tape packaging suited for automated PCB assembly processes.
The LQW series inductors are commonly used for antenna matching circuits to maintain reception and transmission sensitivity, as well as choke circuits where high current levels flow, offering high reliability and performance.
Wirewound construction affords high Q value and low DC resistance. Compact surface mount 2015 package for space-saving PCB layout. Wide temperature range supports diverse operating environments. Non-magnetic core reduces interference and enhances signal quality.
RoHS compliant with molded design for durability. Embossed tape packaging for efficient pick-and-place assembly. Suitable for antenna matching and choke circuit applications.
This Murata inductor is a reliable choice for electronic engineers in RF design, telecommunications, wireless networking, automotive electronics, and other industrial electronic applications. For more Surface Mount Inductors and related products, explore the Electronics Components category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 0.82μH with a tolerance of ±5%.
The dimensions of the 2015 package are 2.09mm in length, 1.53mm in depth, and 1.42mm in height.
It supports a maximum DC current rating of 180mA.
The minimum quality factor (Q) is 23, ensuring efficient performance in filtering applications.
The maximum self-resonant frequency is 230MHz, making it suitable for high-frequency designs.
The operating temperature range is from -55°C to 125°C, allowing for use in various environments.
It features a non-magnetic core material, which reduces magnetic interference in sensitive circuits.
The inductor has a low DC resistance of 2.35Ω, which helps minimize power loss.
It is packaged in embossed tape, which is designed for automated assembly processes.
This model is RoHS compliant, ensuring it meets environmental regulations.
It is commonly used in antenna matching circuits and choke circuits, particularly in RF design and telecommunications.
The country of origin for this inductor is Japan.
