MEAN WELL IP67 1 Output LED Driver, 200V Output Voltage, 100W Power, 600mA Constant Current, DALI Dimming

Free Delivery in India | Lowest Global Shipping Charges

MEAN WELL IP67 1 Output LED Driver, 200V Output Voltage, 100W Power, 600mA Constant Current, DALI Dimming

Name: MEAN WELL IP67 1 Output LED Driver, 200V Output Voltage, 100W Power, 600mA Constant Current, DALI Dimming
Brand: MEAN WELL
SKU: 182538



Category LED Drivers Brand MEAN WELL Condition New

Specifications

Country of Origin	India
Brand	MEAN WELL
Model	IP67
IP Rating	IP67
Mount Type	Screw
Series	ELG-100-C
Configuration	Encapsulated
Sub Type	LED Driver
Operating Modes	Constant Current
Number of outputs	1
Terminal type	Wire
Maximum Output Power	100W
Input Voltage	180, 305, 255, 431V ac
Output Voltage	200V
Power Dissipation	100W
Standards/Approvals	CB, CE:CCC, cULus Recognized, EN61347-1, EN61347-2-13, EN62384, ENEC, PFC, UL8750
Dimming Operation	DALI
Primary Type	DC-DC, AC-DC
Driver Current	600mA
Standards/ApprovalsCB, CE	CCC, cULus Recognized, EN61347-1, EN61347-2-13, EN62384, ENEC, PFC, UL8750
CB, CE	CCC, cULus Recognized, EN61347-1, EN61347-2-13, EN62384, ENEC, PFC, UL8750

Key Features

Fan-less design ensuring high efficiency up to 91 percent.
Supports DALI dimming operation for flexible lighting control.
Robust full metal housing providing IP67 protection suitable for harsh environments.
Wide input voltage range of 180 to 431V AC supports diverse electrical conditions.
Constant current output with one output channel.
Built-in active power factor correction for improved power quality.
Potentiometer and PWM signal dimming options available.
Compliance with CB, CE, CCC, cULus, EN61347, EN62384, ENEC, and UL8750 standards.

Product Description

MEAN WELL ELG-100-C500DA IP67 1 Output LED Driver is a high-performance, dimmable constant current LED driver delivering 100 watts power with output voltage of 200V and driver current of 600mA. Designed with an encapsulated full metal housing, it achieves an IP67 ingress protection rating, ensuring durability in demanding industrial and outdoor environments.

This LED driver features a fan-less design that enhances reliability and achieves up to 91 percent efficiency, making it energy efficient for long-term use. The wide input voltage range from 180V to 431V AC allows for versatile deployment across various power systems.

Equipped with DALI dimming operation, this driver supports flexible lighting control through both potentiometer and PWM signal dimming options. The built-in active power factor correction (PFC) improves power quality and reduces harmonic distortion.

The ELG-100-C500DA series conforms to international safety and performance standards such as CB, CE, CCC, cULus, EN61347-1, EN61347-2-13, EN62384, ENEC, and UL8750 certifications, assuring compliance with regulatory requirements.

Industrial applications include LED street lighting, architectural lighting, bay lighting, floodlighting, and other energy-efficient LED illumination needs, suited for outdoor and commercial lighting projects requiring IP67 rated robust power supplies.

Fan-less design yields high efficiency rating up to 91 percent. IP67 full metal encapsulated housing for superior environmental protection. Wide input voltage range supports varied industrial power supply conditions. DALI dimming and PWM signal options enable precise light intensity control.

Active PFC function enhances power factor and efficiency. Single output constant current LED driver with 600mA output. Multiple international compliance certifications ensure safety and reliability. Ideal for LED street, architectural, bay, and flood lighting applications.
