KEMET R60 Film Capacitor, 22 nF, ±5% Tolerance, 630 V DC, 220 V AC, Through Hole Mount R60PF2220AA30J

Free Delivery in India | Lowest Global Shipping Charges

KEMET R60 Film Capacitor, 22 nF, ±5% Tolerance, 630 V DC, 220 V AC, Through Hole Mount R60PF2220AA30J

Name: KEMET R60 Film Capacitor, 22 nF, ±5% Tolerance, 630 V DC, 220 V AC, Through Hole Mount R60PF2220AA30J
Brand: KEMET
SKU: 180958
Price: 0.37 USD
Availability: InStock



Category Film Capacitor Brand KEMET Condition New

Specifications

Country of Origin	India
Capacitance Range	0.001 μF - 150.0 μF
Voltage Range	50 to 1000 V dc
Brand	KEMET
Height	11mm
Length	13mm
Model	R60PF2220AA30J
Packaging	Bag
Width	5mm
Mount Type	Through Hole
Series	R60
Maximum Operating Temperature	105°C
Tolerance	±5 %
Capacitance	22nF
Minimum Operating Temperature	-55°C
Climatic category	55/105/56
Lead Length	25mm
Standards/Approvals	RoHS, IEC 60286-2, UL 94V-0
Package/Case	Plastic
Pin Count	2
Rated AC Voltage	220V ac
Rated DC Voltage	630V dc
Lead Pitch	10mm
Lead Diameter	0.6mm
Automotive Standard	AEC-Q200
Capacitance tolerance	±5%, ±10%, ±20%
Lead Spacing	10.0 to 37.5 mm

Key Features

Designed for through hole mount with 10 mm lead pitch and 25 mm lead length.
Features a self-extinguishing plastic case with thermosetting resin meeting UL 94V-0 standards.
Operating temperature ranges from -55°C to +105°C for reliable performance.
Complies with RoHS, IEC 60286-2, and automotive AEC-Q200 standards.
Suitable for oscillator, timing, blocking, bypassing, and coupling applications in low voltage circuits.
Capacitance range of the series spans 0.001 μF to 150 μF with voltage range up to 1000 V DC.

Product Description

KEMET R60PF2220AA30J is a high-quality film capacitor from the R60 Series, designed with polyester dielectric and radial tinned wire leads for through hole mounting. This capacitor provides a capacitance of 22 nF with a tolerance of ±5%, and is rated for 630 V DC and 220 V AC, making it versatile for various electronic circuits.

The capacitor is housed in a plastic package that meets UL 94V-0 flame retardant standards, ensuring safety and durability in industrial and laboratory applications. It operates reliably within a temperature range of -55°C to +105°C, suitable for harsh environments including automotive systems compliant with AEC-Q200 certification.

Typical uses include oscillator circuits, timing control, blocking, bypassing, coupling, and interference suppression in low voltage electronics. Its lead pitch of 10 mm and lead length of 25 mm facilitate easy through hole PCB assembly. The capacitor's dimensions are compact at 13 mm length, 5 mm width, and 11 mm height, with leads 0.6 mm in diameter.

The R60 Series capacitors cover a broad capacitance range from 0.001 μF to 150 μF and voltage ratings from 50 to 1000 V DC. Additional features include self-healing properties and compliance with RoHS and IEC 60286-2 standards, ensuring environmental and safety compliance.

Designed for through hole mounting with radial tinned wire leads. Self-extinguishing plastic case with thermosetting resin for enhanced durability. Wide operating temperature range from -55°C to +105°C. Meets automotive quality standards with AEC-Q200 compliance.

Ideal for blocking, coupling, decoupling, bypassing, and interference suppression. Compact size with 10 mm lead pitch and 25 mm lead length. Environmental compliance includes RoHS and IEC 60286-2 certifications.

This Film Capacitor is well-suited for industrial, automotive, laboratory, HVAC, and manufacturing electronics applications requiring stable and precise capacitance. Browse more capacitors and related components at EnvMart for your specific design needs.
