TDK 10 nF 50V DC Multilayer Ceramic Capacitor X7R Dielectric Surface Mount 0402 C1005X7R1H103K050BB



Category Multilayer Ceramic Capacitors Brand TDK Condition New

Specifications

Country of Origin	India
Voltage	50V dc
Brand	TDK
Height	0.5mm
Length	1mm
Model	C1005X7R1H103K050BB
Packaging	Tape & Reel
Width	0.5mm
Mount Type	Surface
Construction	Stacked
Termination Type	Solder
Maximum Operating Temperature	125°C
Tolerance	±10 %
Capacitance	10nF
Minimum Operating Temperature	-55°C
Standards/Approvals	REACH, RoHS
Package/Case	0402
Dielectric	X7R

Key Features

This capacitor features the X7R dielectric suitable for general purpose electronic applications.
The compact 0402 package size ensures suitability for space-constrained PCB layouts.
It exhibits stable capacitance from -55°C to 125°C operating temperature range.
Construction uses stacked multilayer design delivering low ESR and low ESL.
It is supplied in tape and reel packaging for efficient automated PCB assembly.
The solder termination type provides reliable electrical connections.
Complies with REACH and RoHS standards ensuring environmental conformity.
No polarity orientation, simplifying the design process.

Product Description

TDK presents the C1005X7R1H103K050BB, a professional grade 10 nF multilayer ceramic capacitor designed for surface mount technology (SMT) applications. Utilizing the robust X7R dielectric material, it operates reliably within a voltage rating of 50V DC and a tolerance of ±10%.

This capacitor features a compact 0402 package with dimensions of 1 mm length, 0.5 mm width, and 0.5 mm height, making it ideal for densely populated electronic circuit boards in mobile devices, telecommunications equipment, AV systems, and industrial robotics. The stacked multilayer construction enhances mechanical strength and ensures high reliability even under standard operating conditions.

The product offers excellent frequency characteristics with low equivalent series resistance (ESR) and low equivalent series inductance (ESL), resulting in minimal self-heating and high resistance to ripple currents. As a non-polar device, it facilitates simplified circuit design without concern for polarity.

The capacitor is rated to function over a broad temperature range from -55°C to a maximum of 125°C, suiting a variety of industrial, commercial, and consumer electronics environments. It is delivered in tape and reel packaging format, compatible with automated pick-and-place manufacturing processes, enhancing assembly efficiency.

This capacitor is compliant with REACH and RoHS environmental standards, guaranteeing restricted hazardous substance usage. The solder termination ensures robust mechanical and electrical connections to PCB pads. Typical applications include power supply circuits, general electronics, computer and personal equipment, and home appliances.

Choose TDK for dependable multilayer ceramic capacitors that balance size, performance, and environmental compliance for varied industrial and commercial electronic applications. Explore more quality components and technical expertise within the MLCCs - Multilayer Ceramic Capacitors category at EnvMart.
