ROHM 40 V 120 mA Schottky Barrier Diode Surface Mount SOT-23 Package BAS40-04HYFHT116
Specifications
| Country of Origin | India |
|---|---|
| Brand | ROHM |
| Height | 1.15mm |
| Length | 3.1mm |
| Model | BAS40-04HYFHT116 |
| Width | 1.5mm |
| Mount Type | Surface |
| Series | BAS40 |
| Package Type | SOT-23 |
| Standards/Approvals | RoHS |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 120mA |
| Peak Reverse Repetitive Voltage Vrrm | 40V |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 10μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 600mA |
| Maximum Forward Voltage Vf | 1V |
Key Features
- The diode features a Schottky barrier structure for low forward voltage drop and fast switching.
- It supports a maximum continuous forward current of 120 mA for reliable operation.
- The package is a commonly used SOT-23 surface mount type with 3 pins.
- Peak reverse repetitive voltage rating of 40 V ensures suitability for low-voltage rectification.
- It complies with RoHS and AEC-Q101 automotive standards for quality and reliability.
- Low peak reverse current of 10 μA reduces leakage in circuits.
- Maximum forward voltage is rated at 1 V, optimizing efficiency.
- Peak non-repetitive forward surge current of 600 mA supports transient conditions.
Product Description
ROHM BAS40-04HYFHT116 Schottky Barrier Diode is designed for efficient small current rectification in automotive and general electronic applications. Featuring a low forward voltage and high reliability, this diode is housed in a compact SOT-23 surface mount package.
The diode supports a maximum continuous forward current of 120 mA and a peak reverse repetitive voltage of 40 V, making it suitable for low-voltage circuit protection and switching power supply uses. Its Schottky structure ensures fast switching speed and low power dissipation.
Compliance with RoHS and the AEC-Q101 automotive standard highlights its quality and suitability for harsh automotive environments. Leakage current is minimized with a peak reverse current rated at 10 μA, which helps in reducing power loss.
Its small physical footprint - 3.1 mm in length, 1.5 mm in width, and 1.15 mm in height - makes it ideal for compact PCB designs. The device can handle peak surge currents up to 600 mA, protecting the circuit under transient conditions.
The diode incorporates a Schottky barrier design for enhanced efficiency and low voltage drop. Surface mount SOT-23 packaging permits automated high-density PCB assembly. Meets stringent automotive quality standards with AEC-Q101 certification.
Dimensions facilitate compact and space-saving electronic designs. Reduced leakage current maximizes energy efficiency. High surge current capacity supports transient and fault conditions without damage. Ideal for power rectification in automotive, industrial, and consumer electronics.
This diode is a reliable component choice for industries requiring durable and efficient semiconductors such as automotive electronics, power supplies, and signal circuits. Its combination of compact size, electrical performance, and compliance standards make it suitable for a broad range of electronic design environments.
Explore more ROHM semiconductors and discrete electronic components for your project needs at EnvMart.
Explore more products in our Schottky Diode category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for this model is 120 mA.
It has a peak reverse repetitive voltage rating of 40 V, suitable for low-voltage applications.
This diode is housed in a SOT-23 surface mount package, which is commonly used for compact designs.
The maximum forward voltage for this diode is rated at 1 V, optimizing efficiency in circuits.
It can handle a peak non-repetitive forward surge current of 600 mA, supporting transient conditions.
The dimensions of this model are 3.1 mm in length, 1.5 mm in width, and 1.15 mm in height.
The peak reverse current is rated at 10 μA, which helps reduce leakage in circuits.
This model complies with the AEC-Q101 automotive standard, ensuring quality and reliability in automotive applications.
Yes, this diode complies with RoHS standards, indicating it meets environmental regulations.
This diode is a Schottky rectifier, designed for efficient small current rectification.
The SOT-23 package of this diode has 3 pins.
It is suitable for automotive, industrial, and consumer electronics applications requiring efficient rectification.
