Samtec Pin Header 7 Contacts 2.54 mm Pitch 1 Row Unshrouded Through Hole TSW-107-05-T-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Model | TSW-107-05-T-S |
| Mount Type | Through Hole |
| Special Features | Many options fo |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 7 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Contact System | .025" (0.635 mm) square post |
Key Features
- Constructed with glass filled polyester housing for robust insulation.
- Contact material is phosphor bronze plated with gold for enhanced conductivity and durability.
- Suitable for board-to-board connection applications.
- Operating temperature range from -55°C to 125°C ensuring reliable performance.
- Designed for 550V maximum voltage applications.
- Features a .025" (0.635 mm) square post contact system.
- Vertical orientation with solder termination type.
- Unshrouded and straight orientation for easy access and placement.
Product Description
The Samtec TSW-107-05-T-S Pin Header is a high-quality electronic component designed for reliable board-to-board connections in various industrial and electronic applications. This connector features 7 contacts arranged in a single row with a 2.54 mm pitch, which is a standard spacing compatible with a wide range of PCBs and connectors.
The housing is constructed from glass filled polyester, providing excellent insulation and mechanical strength. Contacts made from phosphor bronze with gold plating enhance electrical conductivity and resist corrosion for longer service life.
The pin header is unshrouded with a straight, vertical orientation and uses a through hole mount termination method, making it suitable for PCB assembly with solder. It is designed to operate safely up to 550V and within a temperature range from -55°C to 125°C, ensuring durability in demanding environments.
Its .025" (0.635 mm) square post contact system further ensures secure and precise connections. This product is ideal for industrial, electronic manufacturing, and repair applications requiring high performance and reliability.
Constructed with glass filled polyester housing for robust insulation. Contact material is phosphor bronze plated with gold for enhanced conductivity and durability. Suitable for board-to-board connection applications. Operating temperature range from -55°C to 125°C ensuring reliable performance.
Designed for 550V maximum voltage applications. Features a .025" (0.635 mm) square post contact system. Vertical orientation with solder termination type. Unshrouded and straight orientation for easy access and placement.
Samtec pin headers are widely used in electronics industry, manufacturing, automotive, telecommunications, and other commercial applications wherever dependable electrical connections are needed.
Explore more high-quality electronic connectors and components in the Electronics & Electricals category on EnvMart.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating for this pin header is 550V, making it suitable for high-voltage applications.
This model features a contact pitch of 2.54 mm, which is a standard spacing for many PCB connections.
The contacts are made from phosphor bronze and are plated with gold to enhance conductivity and resist corrosion.
It operates within a temperature range of -55°C to 125°C, ensuring reliable performance in various environments.
This pin header has 7 contacts arranged in a single row.
This model uses a through hole mounting method, which is suitable for PCB assembly with solder.
The pin header has a straight orientation, allowing for easy access and placement during installation.
It features a solder termination type, which is common for secure PCB connections.
This model is unshrouded, providing easier access for connections.
The housing is constructed from glass filled polyester, offering robust insulation and mechanical strength.
It is suitable for board-to-board connection applications in various industrial and electronic sectors.
The contact system features a .025" (0.635 mm) square post design for secure and precise connections.
