Norcomp CDF 25 Way Right Angle 2.77 mm Pitch Surface D-Sub Connector with 4-40 Screw Female CDFR17W2213L211
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 1000V |
| Brand | Norcomp |
| Orientation | Right Angle |
| Current | 5A |
| Model | CDFR17W2213L211 |
| Mount Type | Surface |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Brass |
| Series | CDF |
| Mounting Hardware | 4-40 Screw |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -25°C |
| Pitch | 2.77mm |
| Contact Plating | Gold |
| Number of Contacts | 25 |
| Contact Gender | Female |
| Connector Gender | Female |
| Connector Type D | Standard |
Key Features
- Supports 25 contacts for extensive connectivity.
- Rated for 5A current and 1000V voltage operation.
- Right angle orientation designed for surface mounting applications.
- Constructed with polybutylene terephthalate housing for durability.
- Gold-plated brass female contacts ensure excellent conductivity.
- Mounting hardware includes 4-40 screws for secure attachment.
- Operates reliably within temperature range -25°C to 85°C.
- Connector shell features nickel-plated steel for robust protection.
Product Description
Norcomp CDFR17W2213L211 is a 25 Way Right Angle Surface Mount D-Sub Connector designed with a 2.77 mm pitch for precise electrical connections in demanding electronics and industrial applications. This female connector features gold-plated brass contacts housed in a durable polybutylene terephthalate body, ensuring low resistance and high reliability over extended use.
The connector is engineered with a nickel-plated steel shell and silicon O-ring for enhanced protection and longevity. Rated for operation at 5 amps current and up to 1000 volts, it supports high-performance electrical transmission with an insulation resistance of 5 Gohms. Its right angle orientation and surface mount type suit compact PCB designs, making it ideal for electronics manufacturing and repair.
Operating temperature ranges from -25°C to +85°C ensure use across diverse environmental conditions. Mounting hardware includes 4-40 threaded screws to secure the connector firmly, preventing loosening from vibrations or shocks common in industrial environments.
This connector is widely applicable in industrial electronics, manufacturing equipment, HVAC systems, automation devices, and telecommunications hardware requiring reliable female D-sub connections. The product meets Norcomp’s quality assurance and is manufactured in Taiwan, Province of China.
Supports 25 contacts for extensive connectivity. Rated for 5A current and 1000V voltage operation. Right angle orientation designed for surface mounting applications. Constructed with polybutylene terephthalate housing for durability.
Gold-plated brass female contacts ensure excellent conductivity. Mounting hardware includes 4-40 screws for secure attachment. Operates reliably within temperature range -25°C to 85°C. Connector shell features nickel-plated steel for robust protection.
Insulation resistance of 5 Gohms for safe electrical isolation. Manufactured in Taiwan, Province Of China with high-quality standards. Explore quality Norcomp connectors and compatible products in the EnvMart catalog for industrial and electronic component solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a current of 5A.
It can operate at a maximum voltage of 1000V.
It operates reliably within a temperature range of -25°C to +85°C.
This connector supports 25 contacts for extensive connectivity.
The housing is made of polybutylene terephthalate, and the contacts are gold-plated brass.
It is designed for surface mounting and includes 4-40 screws for secure attachment.
This model features a right angle orientation, suitable for compact PCB designs.
It has an insulation resistance of 5 Gohms for safe electrical isolation.
It is manufactured in Taiwan, Province of China.
The pitch size of this connector is 2.77 mm.
It is widely applicable in industrial electronics, manufacturing equipment, HVAC systems, automation devices, and telecommunications hardware.
This connector has a female gender for both contacts and connector type.
