RS PRO PCB Mount Toggle Switch On-Off-On SPDT Solder Terminal 10A 250 V ac 206-7002

RS PRO 206-7002 is a high-quality toggle switch designed for electrical and industrial control applications requiring reliable PCB mounting solutions. This single pole double throw (SPDT) switch features an On-Off-On operation mode with solder terminal connections, enabling switching between two output circuits with an off position in the center.

The switch supports a contact current rating of 10A at 250 V ac, making it suitable for moderate power applications in telecommunications, aerospace, automotive, instrumentation, and industrial control solutions.

Constructed with a plastic actuator, brass with nickel plating for the bushing, and an iron nickel-plated housing, this toggle switch ensures mechanical robustness and resistance to environmental factors. The actuator length is 42 mm, with overall dimensions compact for PCB integration.

Designed with IP40 front panel protection, the switch can withstand typical industrial environments with protection against solid objects larger than 1 mm. It operates reliably between temperatures of -20°C and +55°C.

The mechanical life cycle rating of 10,000 cycles ensures durability and longevity under repetitive switching operations. This model is UL and cUL certified and compliant with RoHS standards, ensuring safety and environmental compliance.

This toggle switch supports a single pole double throw (SPDT) contact configuration. It features an On-Off-On switch operation to enable circuit changeover functionality. The switch is rated for a contact current of 10A at 250V ac.

Boasts IP40 front panel protection suitable for moderate environments. Constructed with a plastic actuator and metal nickel-plated housing for durability. Designed for PCB mounting with solder terminal connections for reliable PCB integration.

Operates efficiently within a temperature range from -20°C to +55°C. Has a mechanical life expectancy of 10,000 cycles ensuring long term reliability. UL and cUL approved, RoHS compliant to meet industry standards.

This toggle switch is ideal for telecommunications equipment, aerospace instrumentation, automotive electrical systems, industrial control panels, and material handling machinery. Its precise switching and robust construction make it suitable for demanding industrial and commercial electrical applications.

RS PRO offers a wide range of toggle switches designed to meet various industry needs, and the 206-7002 model embodies reliability and quality for PCB mounted Toggle Switch requirements.
