LEM HAT Series Hall Effect Current Transformer 600 A 15V 15mm Bore HAT 600-S

LEM HAT 600-S Hall Effect Current Transformer is a precise measuring instrument designed for industrial and electrical applications requiring monitoring of DC, AC, and pulse currents up to 600 A. Its open loop topology and Hall effect principle provide accurate current sensing combined with galvanic isolation between primary and secondary circuits, ensuring safe operation.

The device features a 15mm bore diameter, allowing for easy installation around conductors and busbars. Its durable housing constructed from UL94-V0 rated self-extinguishing insulating material enhances safety and longevity. Operating efficiently within a wide temperature range from -40°C to 105°C, the transformer is suitable for demanding industrial, automation, and control gear environments.

The mount type is busbar plug-in, facilitating quick integration into electrical distribution frameworks. With a supply voltage of 15V, it guarantees stable output signals compatible with connected measurement or control systems.

Typical applications include process control, current monitoring in electrical panels, and industrial automation systems requiring precise current measurement with isolation. It complies with JEDEC JESD46-B standards consolidating quality and reliability.

Open loop current transducer using Hall effect measuring principle. Measures DC, AC, and pulse currents up to 600 A. Galvanic isolation between primary and secondary circuits. Housing made from UL94-V0 self-extinguishing insulating material.

Busbar plug-in mount type for simple installation. Wide operating temperature range of -40°C to 105°C. Compact dimensions: 90mm width, 40mm depth, 15mm bore diameter. Supply voltage of 15V for stable operation. Complies with JEDEC JESD46-B standards.

This current transformer from LEM is ideal for industrial machines, electrical automation, HVAC systems, and process control systems requiring reliable current measurement with safety isolation. Browse EnvMart's extensive range of Current Transformers for diverse electrical applications.
