TDK-Lambda DC/DC Converter 12V DC 500mA 18V Input 9V DC Input 6W Surface Mount CC6-1212SR-E

Free Delivery in India | Lowest Global Shipping Charges

TDK-Lambda DC/DC Converter 12V DC 500mA 18V Input 9V DC Input 6W Surface Mount CC6-1212SR-E

Name: TDK-Lambda DC/DC Converter 12V DC 500mA 18V Input 9V DC Input 6W Surface Mount CC6-1212SR-E
Brand: TDK-Lambda
SKU: 164929
Price: 339.87 USD
Availability: InStock



Category DC/DC Converter Brand TDK-Lambda Condition New

Specifications

Country of Origin	Japan
Voltage	Converters / DC-DC Converters TDK-Lambda CC-E DC/DC Converter, 12V dc/ 500 mA, 1
Brand	TDK-Lambda
Efficiency	0.85%
Length	22.86mm
Model	CC6-1212SR-E
Depth	21.1mm
Gross Weight	5.8g
Width	22.8mm
Mount Type	Surface
Series	CC-E
Maximum Operating Temperature	85°C
Package Type	Surface Mount
Minimum Operating Temperature	-40°C
Number of outputs	1
Maximum Output Power	6W
Maximum Input Voltage	18V
Minimum Input Voltage	9V dc
Number of Pins	7
Output Voltage 1	12V dc
Output Current 1	500mA
Isolation Voltage	500V
Input Ratio	2:1
Input Ratio2	1

Key Features

Designed for efficient DC voltage conversion with 0.85% efficiency.
Wide input voltage range from 9V DC minimum to 18V maximum.
Compact surface mount design with dimensions 22.86mm length, 22.8mm width, and 21.1mm depth.
Operates reliably between -40°C and 85°C ambient temperature.
Provides isolation voltage of 500V for safety and noise reduction.
Features 7 pins and single output configuration with output voltage adjustment range of ±3%.
Compact weight of 5.8 grams suitable for various electronic applications.
Ideal for telecommunications, industrial equipment, and consumer electronics.

Product Description

TDK-Lambda CC6-1212SR-E DC/DC Converter is a compact and efficient power supply solution delivering 12 volts DC output at 500 mA with a maximum output power of 6 watts. This surface mount device offers a wide input voltage range from 9 volts DC to 18 volts, making it highly versatile for various electronic circuits and sub-circuits that require a controlled DC voltage conversion.

The converter features a strong isolation voltage of 500 volts between input and output circuits, enhancing operational safety and reducing electrical noise interference. Its ultra-compact dimensions - 22.86 mm in length, 22.8 mm in width, and 21.1 mm in depth - enable integration into space-constrained applications.

Operating efficiently at 0.85% efficiency, it maintains reliable performance within ambient temperatures spanning from -40°C to 85°C. The 7-pin surface mount package supports single output configuration and allows output voltage adjustments within a ±3% range, providing flexibility for precise tuning.

Designed for demanding industrial, telecommunications, and consumer electronics applications, this device is part of the CC-E series known for compact footprint and robust performance. Its lightweight of 5.8 grams further simplifies mounting on printed circuit boards.

Manufactured in Japan, the CC6-1212SR-E assures quality and longevity. The product is RoHS compliant and suitable for use in environments where high reliability and safety are paramount.

Efficient DC voltage conversion with 0.85% efficiency. Wide 9 - 18V DC input voltage range for versatile power sourcing. Compact surface mount package measuring 22.86 x 22.8 x 21.1 mm. Isolation voltage of 500V for improved safety and noise reduction.

Operates reliably from -40°C to 85°C ambient temperature. Single output with output voltage adjustment ±3% for precise control. Lightweight design weighing only 5.8 grams. Applications include telecommunications, industrial, and consumer electronics.

Made in Japan ensuring high manufacturing standards.

This product is ideal for engineers and designers seeking a compact, reliable, and efficient DC/DC converter. Browse the EnvMart Electronics & Electricals category for related DC/DC Converters and power supply components to complete your design projects.
