Eaton xPole Miniature Circuit Breaker, 3-Pole, 20A, Type D, 400V AC, 48V DC, 10 kA Breaking Capacity 236466 PXL-D20/3

Eaton 236466 PXL-D20/3 miniature circuit breaker is a three-pole device designed for protection of electrical circuits rated at 20 amperes with Type D tripping characteristics. It supports both alternating current (400V AC) and direct current (48V DC) voltage standards, making it versatile for diverse applications in industrial, commercial, and residential environments.

Manufactured under strict IEC and EN 60898 standards, this breaker ensures reliable interruption of electrical faults with a high breaking capacity of 10 kiloamperes. Its electromagnetic instantaneous tripping mechanism provides prompt response to fault conditions, enhancing system safety.

The circuit breaker features a robust toggle switch reset actuator and mounts on standard DIN rails with a quick-fit action and three locking positions, facilitating straightforward installation and maintenance. Its IP20 rating guarantees protection against finger contact and back-of-hand safety.

Compact in size, measuring 80mm in width, 60mm in depth, and 52.5mm in height, this breaker fits efficiently into electrical panels. The device is bus bar compatible with double terminals at both top and bottom ends, which support lifting jaws for secure wire connections and flexible rail arrangements.

Eaton, formerly known as Moeller, ensures product reliability and performance, catering to electrical distribution needs with this PXL series miniature circuit breaker. This product originates from Austria, reflecting high manufacturing standards.

Rated for 400 volts AC and 48 volts DC applications ensuring versatility. Type D tripping characteristic suitable for motor and transformer circuit protection. 10 kA breaking capacity for high fault current interruption capability.

Compact 3-pole design with easy DIN rail mount. Toggle switch and electromagnetic trip mechanism for fast fault response. Bus bar compatible with double terminal connections top and bottom. IP20 rated for finger and back-of-hand protection.

Conforms to IEC and EN 60898 electrical safety standards. Manufactured in Austria with premium quality and reliability.

For users requiring reliable Miniature Circuit Breakers for electrical panel protection in industrial, laboratory, HVAC, manufacturing, and commercial applications, the Eaton xPole PXL-D20/3 is a robust choice. Discover more high-quality Eaton circuit breakers and electrical protection devices on EnvMart.
