Eaton xPole Miniature Circuit Breaker 2-Pole 10A Type C 400V AC 48V DC 10 kA Breaking Capacity 236285 PXL-C10/2
Specifications
| Country of Origin | Austria |
|---|---|
| Range | xPole |
| Brand | Eaton |
| Height | 35mm |
| Model | 236285 PXL-C10/2 |
| Depth | 60mm |
| IP Rating | IP20 |
| Width | 80mm |
| Mount Type | DIN Rail |
| Current Rating | 10A |
| Series | PXL |
| Breaking Capacity | 10kA |
| Number of Poles | 2 |
| Standards/Approvals | IEC, EN 60898 |
| Rated AC Voltage | 400V ac |
| Rated DC Voltage | 48V dc |
| Tripping Characteristics | Type C |
| Tripping Mechanism | Electromagnetic |
| Reset Actuator Type | Toggle Switch |
| Break Time | Instantaneous |
Key Features
- Rated for 10A current with type C tripping characteristic.
- Operates safely at 400V AC and 48V DC voltages.
- Offers a robust breaking capacity of 10 kA to interrupt high fault currents.
- Compact dimensions of 80mm length, 35mm width, and 60mm depth for DIN rail mounting.
- Equipped with a toggle switch for easy reset after tripping.
- Electromagnetic tripping mechanism ensures fast response to faults.
- IP20 rated for protection against solid objects larger than 12 mm.
- Stable operation in temperature ranges from -25°C to 55°C.
Product Description
Eaton 236285 PXL-C10/2 Miniature Circuit Breaker provides high-standard protection for electrical circuits in industrial, commercial, and residential setups. With a 2-pole configuration and 10A current rating, this device safeguards installations from overloads and short circuits efficiently.
The type C tripping characteristic enables reliable current management suitable for a variety of applications. It operates under rated AC voltage of 400V and DC voltage of 48V, handling fault currents up to 10 kA without damage. The MCB features a compact design with dimensions 80mm (length) x 35mm (width) x 60mm (depth), making it perfect for standard DIN rail mounting.
Its toggle switch reset actuator allows for straightforward manual reset post-tripping, while the electromagnetic mechanism provides instantaneous response to electrical faults. The product meets IEC and EN 60898 standards, ensuring robust and safe performance.
Engineered to function reliably across temperatures from -25°C to 55°C, the device reduces current carrying capacity linearly with increasing temperature to preserve connected circuits. It accommodates conductors up to 25 mm² for both solid and multi-stranded wire types, offering installation flexibility.
10A current rating with type C tripping for precise overload protection. Rated for 400V AC and 48V DC operation. 10 kA breaking capacity protects against high fault currents. Compact form factor suitable for DIN rail mounting in electrical panels.
Toggle switch provides easy and quick circuit reset. Electromagnetic tripping mechanism ensures immediate fault interruption. IP20 protection rating for safety against solid foreign objects. Wide temperature operating range from -25°C to 55°C.
Compatibility with conductors up to 25 mm² cross-section. Compliance with IEC and EN 60898 standards for quality assurance.
This Eaton Miniature Circuit Breaker is ideal for residential and commercial switchgear, building management systems, and automation panel applications. Its high breaking capacity enhances safety by effectively interrupting dangerous fault currents, minimizing potential damage. The product is manufactured in Austria, maintaining high-quality engineering standards.
For more industrial-grade circuit protection solutions, explore related Eaton products at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 10A, making it suitable for various electrical applications.
It operates safely at a rated AC voltage of 400V and a DC voltage of 48V.
It offers a robust breaking capacity of 10 kA, allowing it to interrupt high fault currents effectively.
The dimensions are 80mm in length, 35mm in width, and 60mm in depth, making it compact for installation.
It features an electromagnetic tripping mechanism that ensures instantaneous response to electrical faults.
It is equipped with a toggle switch that allows for easy manual reset after tripping occurs.
The unit has an IP20 rating, providing protection against solid objects larger than 12 mm.
It operates reliably within a temperature range of -25°C to 55°C.
It complies with IEC and EN 60898 standards, ensuring quality and safety in performance.
This miniature circuit breaker is designed for DIN rail mounting, suitable for standard electrical panels.
It can accommodate conductors up to 25 mm² for both solid and multi-stranded wire types.
This model is manufactured in Austria, adhering to high engineering standards.
