Samtec TMM Series Straight Surface Pin Header, 4 Contacts, 2 mm Pitch, 2 Row, Unshrouded TMM-102-01-F-D-SM
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 281V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 3.2A |
| Model | TMM-102-01-F-D-SM |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | TMM |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 4 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
Key Features
- The header features phosphor bronze contact material plated with gold for excellent conductivity and durability.
- The housing is made from liquid crystal polymer offering high insulation and thermal resistance.
- Designed for surface mount type with straight orientation and male contact gender.
- Operates reliably within a temperature range of -55°C to 125°C.
- Rated for 3.2 A current per contact and up to 281 V voltage.
- Low profile design with 2mm pitch and 2-row configuration enables compact PCB layouts.
- Ideal for industrial, electronic manufacturing, and communication device applications.
- RoHS compliant ensuring environmental safety and regulatory compliance.
Product Description
Samtec TMM-102-01-F-D-SM is a high-quality Straight Surface Pin Header designed for robust board-to-board connection.
This 2 mm pitch, 2-row header includes 4 gold-plated phosphor bronze contacts housed in black liquid crystal polymer providing excellent insulation, mechanical strength, and thermal stability.
Its surface mount design with straight male contacts suits compact PCB assembly requiring reliable electrical connections with a current carrying capacity of 3.2 A per contact and voltage rating up to 281 V.
The header operates across a wide temperature range from -55°C to 125°C, making it suitable for industrial, electronics manufacturing, telecommunications, and power distribution applications.
The unshrouded design allows flexibility in connector mating and inspection. Materials and plating were selected for durability and corrosion resistance ensuring long-term reliability in demanding environments. Samtec ensures that this TMM Series header is RoHS compliant, helping users meet environmental regulation standards.
The header incorporates phosphor bronze contacts with gold plating for superior conductivity and corrosion resistance. Liquid crystal polymer housing offers excellent electrical insulation and mechanical robustness. Surface mount technology aids rapid PCB assembly and soldering processes.
Compact design with 2 mm pitch suitable for high-density electronic and industrial equipment. Wide operating temperature range suitable for harsh environmental conditions. Rated for high current and voltage ensuring safe and reliable performance.
Unshrouded two-row configuration enables versatile connectivity options with other PCB components. Compliance with industry RoHS standards supports environmentally responsible manufacturing. This connector is ideal for various electronic components, power connectors, and industrial electronic assemblies.
Explore the Electronics Components category on EnvMart for complementary products and accessories.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 3.2 A per contact.
It is rated for a maximum voltage of 281 V.
The pin header features a 2 mm pitch between contacts.
The contacts are made of phosphor bronze with gold plating, while the housing is constructed from liquid crystal polymer.
It operates reliably within a temperature range of -55°C to 125°C.
This pin header includes 4 contacts.
It uses solder termination type for connections.
This model is designed as an unshrouded pin header.
The contacts are oriented straight for easy mounting.
The housing is made from liquid crystal polymer, providing high insulation and thermal resistance.
It is ideal for industrial, electronic manufacturing, and communication device applications.
The country of origin for this model is India.
