KEMET R76_125C Film Capacitor ±5 % 560 pF 1 kV DC 600 V AC Through Hole R76QF056050H0J
Specifications
| Country of Origin | China |
|---|---|
| Capacitance Range | 100 pF - 15 μF |
| Brand | KEMET |
| Height | 9mm |
| Length | 13mm |
| Model | R76QF056050H0J |
| Packaging | Bag |
| Width | 4mm |
| Mount Type | Through Hole |
| Series | R76_125C |
| Maximum Operating Temperature | 125°C |
| Tolerance | ±5 % |
| Capacitance | 560pF |
| Minimum Operating Temperature | -55°C |
| Terminal type | Solder |
| Dissipation Factor | 0.1% |
| Lead Length | 25mm |
| Standards/Approvals | IEC 60286-2, RoHS |
| Pin Count | 2 |
| Rated AC Voltage | 600V ac |
| Rated DC Voltage | 1kV dc |
| Lead Pitch | 10mm |
| Lead Diameter | 0.6mm |
| Automotive Standard | AEC-Q200 |
| Capacitance tolerance | ±2.5%, ±5%, ±10% |
| Lead Spacing | 10 mm - 37.5 mm |
| Equivalent Series Resistance ESR | 1.137mΩ |
Key Features
- Constructed with polypropylene and metallized polyester film electrodes for durability.
- Rated operating temperature range from -55°C to 125°C allowing harsh environment use.
- Radial leads with 10 mm pitch and 0.6 mm diameter for secure solder mounting.
- Encapsulated in a self-extinguishing plastic case with thermosetting resin material.
- Typical applications include high-frequency circuits, snubber circuits, and power electronics.
- Meets IEC 60286-2 and RoHS standards, and automotive standard AEC-Q200 certified.
Product Description
KEMET R76QF056050H0J is a high-quality film capacitor featuring a capacitance of 560 pF, rated at 1 kV DC and 600 V AC with a tolerance of ±5%, designed for through hole mounting. This component is engineered with polypropylene film and double metallized polyester film electrodes, providing excellent stability and reliability for various electronic applications.
The capacitor utilizes radial leads of tinned wire, electrically welded to metal electrode layers, ensuring effective current conduction and mechanical strength. Encased in a self-extinguishing, solvent-resistant plastic housing that uses thermosetting resin, it offers robust protection and longevity in harsh industrial environments.
Operating temperature ranges from -55°C to 125°C make it suitable for demanding applications, including resonant circuits, high-frequency high-current scenarios, snubber circuits, and silicon-controlled rectifier (SCR), IGBT, and SiC commutation circuits. Its lead pitch of 10 mm and lead length of 25 mm enable easy PCB integration by soldering.
Certified to IEC 60286-2 and RoHS compliance ensures environmental safety and consistency with global standards. The capacitor also meets the automotive standard AEC-Q200, confirming its reliability in automotive electronic systems.
Constructed with polypropylene film and double metallized polyester electrodes. Rated for 1 kV DC voltage and 600 V AC voltage. Tolerance of ±5% capacitance ensuring precision in circuits. Operating temperature from -55°C up to 125°C for broad environmental application.
Lead pitch of 10 mm and lead diameter of 0.6 mm facilitates through hole mounting. Encapsulated in a flame-retardant, solvent-resistant plastic casing. Compliant with IEC 60286-2, RoHS, and automotive AEC-Q200 standards.
This film capacitor is ideal for industrial, laboratory, manufacturing, and automotive electronics applications where high voltage, high frequency, and temperature reliability are required. Proper use of this capacitor will enhance the performance and durability of electronic assemblies that demand precision and longevity.
Explore more Film Capacitors and electronic components on EnvMart to meet your project or production needs with trusted industrial-grade parts.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance of this model is 560 pF, with a tolerance of ±5%.
It is rated for a DC voltage of 1 kV and an AC voltage of 600 V.
The operating temperature range is from -55°C to 125°C, making it suitable for harsh environments.
The dimensions are 13 mm in length, 4 mm in width, and 9 mm in height.
This model is designed for through hole mounting with a lead pitch of 10 mm and a lead diameter of 0.6 mm.
It meets IEC 60286-2 and RoHS standards, and is certified to the automotive standard AEC-Q200.
The lead length is 25 mm, facilitating easy integration into PCB designs.
It features solder terminals, ensuring secure connections during installation.
The equivalent series resistance (ESR) is 1.137 mΩ.
It is suitable for high-frequency circuits, snubber circuits, and power electronics applications.
It is constructed with polypropylene film and double metallized polyester film electrodes, encapsulated in a self-extinguishing plastic case.
The dissipation factor is 0.1%, indicating low energy loss during operation.
