STMicroelectronics High Voltage Switcher 500 mA 1.05kV 16-Pin SO-16N VIPER267KDTR
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.5mm |
| Length | 10mm |
| Model | VIPER267KDTR |
| Width | 4mm |
| Output Power | 20W |
| Mount Type | Surface |
| Maximum Duty Cycle | 80% |
| Series | VIPER26K |
| Topology | Flyback |
| Maximum Operating Temperature | 150°C |
| Package Type | SO-16N |
| Minimum Operating Temperature | -40°C |
| Switching Frequency | 60kHz |
| Maximum Input Voltage | 23.5V |
| Maximum Output Current | 500mA |
| Standards/Approvals | RoHS |
| Maximum Output Voltage | 1.05kV |
| Minimum Input Voltage | 11.5V |
| Pin Count | 16 |
| Supply Current | 2mA |
| Jittered switching frequency reduces the EMI filter cost | 60 kHz ± 4kHz |
Key Features
- Operates with input voltages ranging from 11.5V to 23.5V.
- Supports a maximum output power of 20 Watts with 16-pin SO-16N package.
- Features a switching frequency of 60 kHz with jitter for reduced EMI filter cost.
- Includes safety features such as hysteretic thermal shutdown and safe auto-restart after faults.
- Embedded E/A with 3.3 V reference and built-in soft-start enhances system reliability.
- Wide operating temperature range from -40°C to 150°C suitable for harsh environments.
- Low standby power consumption below 30 mW at 230 VAC.
- Compact dimensions of 10 mm length, 4 mm width, and 1.5 mm height.
Product Description
STMicroelectronics VIPER267KDTR is a high voltage switcher IC specifically designed for flyback converter applications, delivering a maximum output current of 500 mA and an output voltage up to 1.05 kV. This power management IC is housed in a compact SO-16N 16-pin surface mount package, measuring 10 mm in length, 4 mm in width, and 1.5 mm in height, enabling efficient PCB layout in compact designs.
It supports a wide input voltage range from 11.5V to 23.5V, making it suitable for various AC-DC converter systems. The IC operates at a switching frequency of 60 kHz ± 4 kHz with jittering, which reduces electromagnetic interference (EMI) filter costs and improves overall system performance.
This component includes a 1050 V avalanche-rugged power MOSFET which enhances protection against voltage spikes, embedded high voltage startup circuitry, and sense-FET for accurate current sensing. The device incorporates current mode PWM control along with drain current limit protection and delivers output power up to 20 W.
Reliability enhancing features such as built-in soft-start, safe auto-restart after fault conditions, and hysteretic thermal shutdown assure stable and fault-tolerant operation in industrial and commercial power conversion applications. Standby power consumption is kept low, below 30 mW at 230 VAC, ensuring energy efficiency in standby mode.
The operating temperature range from -40°C to 150°C enables usage in harsh environments typical of industrial, HVAC, manufacturing, and electronic infrastructure systems. Compliance with RoHS standards guarantees environmental safety.
Operates with input voltages ranging from 11.5V to 23.5V. Maximum output voltage of 1.05 kV supports high voltage switching. 20 W output power suitable for low to medium power applications. Jittered 60 kHz switching frequency reduces EMI filtering costs.
Integrated protections include thermal shutdown and safe auto-restart. Compact SO-16N 16-pin surface mount package for space-saving designs. Low supply current of 2 mA for enhanced energy efficiency. Wide operating temperature range from -40°C to 150°C.
1050 V avalanche-rugged power MOSFET improves robustness. Environmentally compliant with RoHS regulations.
STMicroelectronics Power Management ICs are widely used in industrial, commercial, laboratory, and manufacturing sectors requiring compact, efficient AC-DC conversion solutions. For further technical reference, datasheets, and design resources, engineers can explore EnvMart's comprehensive component selection platform.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output voltage of this model is 1.05 kV, suitable for high voltage switching applications.
It operates at a switching frequency of 60 kHz with a jitter of ± 4 kHz, which helps reduce EMI filter costs.
This unit supports an input voltage range from 11.5V to 23.5V, making it versatile for various AC-DC converter systems.
The maximum output current is 500 mA, allowing it to deliver up to 20 Watts of output power.
The dimensions of the SO-16N package are 10 mm in length, 4 mm in width, and 1.5 mm in height.
It includes safety features such as hysteretic thermal shutdown and safe auto-restart after fault conditions, enhancing reliability.
The operating temperature range is from -40°C to 150°C, suitable for harsh environments.
This model uses a flyback topology, which is common for power management applications.
The supply current is 2 mA, contributing to its energy efficiency.
Yes, it complies with RoHS standards, ensuring environmental safety.
The maximum duty cycle is 80%, which is relevant for its operational efficiency.
It is widely used in industrial, commercial, laboratory, and manufacturing sectors requiring compact, efficient AC-DC conversion solutions.
