STMicroelectronics 32-Bit ARM Cortex M0 Microcontroller 48 MHz 256kB FLASH 64-Pin LQFP STM32F091RCT7

STMicroelectronics STM32F091RCT7 is a high-performance 32-bit ARM Cortex M0 microcontroller designed for diverse industrial and commercial applications. Operating at a clock frequency of 48 MHz, it delivers efficient processing capabilities with 256kB of Flash memory and 32kB of SRAM to handle complex firmware and data buffering.

This microcontroller features a 64-pin LQFP surface mount package with compact dimensions (10mm x 10mm x 1.45mm) suitable for PCB space-constrained designs. Its operating voltage range is flexible from 2 V up to 3.6 V, accommodating various power supply conditions.

The STM32F091RCT7 includes advanced analog and digital peripherals such as 16 channels of 12-bit ADCs, one 12-bit DAC with two channels, and two analog comparators. It also offers extensive communication interfaces including up to eight USART ports, two I2C buses, two SPI buses with one supporting I2S, as well as CAN protocol support.

Designed for reliability, this microcontroller supports operation in temperature ranges from -40°C to +105°C, making it suitable for automotive, industrial control, and harsh environment applications. The device contains several timers, including seven 16-bit timers, one 32-bit timer, and an advanced-control PWM timer for precise timing and control applications.

Power management features include multiple power-saving modes to optimize battery life in handheld and portable equipment. The ARM Cortex M0 core employs a 32-bit RISC architecture ensuring fast instruction execution and low power consumption.

Operates at a maximum clock frequency of 48 MHz. Includes 256kB Flash and 32kB SRAM memory. Equipped with a 64-pin LQFP surface mount package. Supports multiple digital communication protocols including USART, SPI, I2C, and CAN.

Wide operating temperature range of -40°C to 105°C. Low power consumption with advanced power-saving modes. Incorporates 16 ADC channels and one 12-bit DAC with two channels. Multiple timers for precise event control and PWM generation.

Robust analog comparators and digital peripherals integrated.

This microcontroller is ideal for applications in embedded systems, industrial automation, automotive controls, consumer electronics, and IoT devices. Explore a wide range of semiconductor and Microcontroller products for your industrial and development needs with EnvMart.
