Cynergy3 Panel Reed Relay with 5V DC Coil, SPNC Contact Configuration, 1000V DC Max, 3A Max, 38Ω Coil Resistance

Cynergy3 DBR70505PU is a high-performance panel reed relay with a 5V DC coil and SPNC contact configuration, designed for advanced electrical and automation applications. It supports a maximum DC voltage of 1000V and can switch up to 3A current, making it suitable for demanding signal conditioning and relay control tasks.

The relay's coil power is rated at 50W with a coil resistance of 38 ohms and offers excellent isolation of 17kV between the coil and contacts. Its compact panel mounting form factor allows for straightforward installation in control panels used across industrial automation, test equipment, and high voltage power supplies.

Manufactured using very high vacuum reed switch technology, with tungsten or rhodium contacts, this relay delivers very high isolation voltages up to 10kV, making it ideal for critical applications including medical devices such as cardiac defibrillators and aerospace instrumentation.

Features include an operating temperature range from -20°C to 70°C and a swift operating time of 2 milliseconds to enable reliable, fast switching cycles. The product also meets UL standards (UR approval), underscoring its safety and reliability in industrial settings.

This relay features a 5V DC coil voltage with a coil resistance of 38 ohms. It supports a maximum switching power of 50W and can handle up to 3A current. The relay has a maximum DC voltage rating of 1000V and an isolation coil to contact voltage of 17kV.

It is panel mount type offering easy installation in control panels and electrical systems. Operating temperature range is from -20°C to 70°C, suitable for varied environments. The relay has a fast operating time of 2ms for efficient response.

Contact resistance is low at 50 milliohms ensuring reliable signal switching. Constructed with high vacuum reed switches and tungsten or rhodium contacts for high reliability. It is UL recognized (UR approval) ensuring safety and compliance with standards.

Dimensions include 60mm length and 18.5mm height for panel integration.

This Cynergy3 panel Reed Relay is well suited for use in industrial automation, laboratory equipment, medical electronics, high voltage power supplies, and test instrumentation. Its high reliability, excellent isolation, and durability make it a preferred choice for critical control and switching tasks.
