Cynergy3 Panel Reed Relay, 5V DC Coil, SPST Contact Configuration, 7000V DC Isolation, 2A Max Current, 28 Ohm Coil Resistance

Cynergy3 DAT70505PU Panel Reed Relay is an advanced electronic component designed for high reliability switching in industrial, medical, and test equipment applications. It features a 5V DC coil and SPST (Single Pole Single Throw) contact configuration to enable precise circuit control with low contact resistance of 250 milliohms. The relay supports a maximum voltage isolation of 7000V DC, safeguarding sensitive electronics from high voltage surges.

This relay uses high vacuum reed switches with Rhodium or Tungsten contacts, achieving excellent AC characteristics and a coil to contact isolation voltage rated at 17kV. The coil power rating is 50W with a coil resistance of 28 ohms, optimized for efficient energy use at the specified coil voltage.

The unit mounts on panels via nylon studs and features wire wrap terminals enabling flexible and secure installation. Its operational temperature range from -20°C to 70°C guarantees dependable functionality across thermal extremes common in industrial and laboratory environments.

With a swift operating time of 3 milliseconds and a switching power capacity of 50W, this relay provides a responsive and durable switching mechanism suitable for cardiac defibrillators, test instruments, and high voltage power supplies. Its construction is UL-approved, ensuring adherence to safety and quality standards.

High isolation voltage protects circuits in high reliability applications. Low contact resistance improves signal integrity and reduces losses. Panel mount design with wire wrap terminals for installation versatility. Wide operating temperature range suitable for diverse industrial environments.

Rhodium and Tungsten contact options tailored for different voltage and resistance requirements. Rapid switching capability supports precision control and timing circuits. Applications include industrial automation, medical devices, high voltage power supplies, and laboratory testing equipment.

This Cynergy3 DAT70505PU Reed Relay is part of the reputable DAT series, originating from the United Kingdom, purpose-built for demanding applications requiring high isolation and reliable switching performance. Browse our extensive range of relays and Reed Relays in the Electronics & Electricals category on EnvMart for compatible and complementary components.
