TE Connectivity 6 Position DPST Rotary Switch, Momentary/Latching, 400mA, 20V AC/DC, Solder Terminal MRJE2604

TE Connectivity MRJE2604 is a miniature 6 position DPST rotary switch designed for reliable switching in compact electronic and automation equipment. It supports both momentary and latching switch operations for versatile control scenarios.

The switch features a solid die cast zinc housing with an epoxy base, providing durability and mechanical strength. It is rated to IP67 standards, offering high protection against dust and water ingress, making it suitable for harsh industrial environments.

With a contact current rating of 400mA and a maximum voltage of 20 volts AC/DC, it is ideal for dry circuit switching applications commonly found in communication and portable test/monitoring equipment. The gold-plated break-before-make contacts provide excellent reliability through a wiping action that extends switch life up to 30,000 operations.

Mounting the switch is convenient, designed for PCB solder terminals and panel cut-out of Ø6.4 mm with a shaft diameter of Ø3.3 mm and length of 19mm. The rotary throw angle is 30°, accessible via a screwdriver slot on the shaft end, enabling easy operation without the need for a knob.

Operating temperature range from -20°C to 70°C ensures performance in varied industrial conditions. Its compact dimensions (11.9 mm diameter and width, 34 mm height, 11.9 mm depth) make it well suited for space-constrained applications.

This rotary switch is compliant with RoHS requirements and manufactured in Japan to high-quality standards, ensuring consistent performance for industrial, electronics, automation, and equipment manufacturing uses.

This Rotary Switch features a double pole, single throw (DPST) contact configuration. It supports six positions with a durable mechanical life of 30,000 cycles. The switch contact current rating is 400mA at 20V AC/DC voltage.

Constructed with a die cast zinc housing and epoxy base for robust and long-lasting performance. IP67 rated enclosure ensures excellent protection against dust and water ingress. Mounts easily on PCB with solder terminal types for straightforward installation.

Operates within a temperature range from -20°C to +70°C for various environmental conditions. Includes a screwdriver-accessible shaft with a 30° angle of throw for precise user control. Suitable for panel or PCB mounting with a panel cut-out diameter of 6.4mm.

Made in Japan, the switch complies with RoHS standards ensuring environmental safety. Explore our wide range of industrial electronic switches and components from TE Connectivity on EnvMart for reliable automation and control solutions.
