Samtec TSM Series Straight Surface Pin Header 26 Contacts 2.54 mm Pitch 2 Row Unshrouded TSM-113-01-L-DV
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 475V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 4A |
| Model | TSM-113-01-L-DV |
| Mount Type | Surface |
| Special Features | Designed specifically for surface mount applications with many options to facilitate processing |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | TSM |
| Termination | Surface mount, mixed technology |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 26 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Mating Pin Length | 5.84mm |
| Contact System | .025" (0.635 mm) square post |
Key Features
- Features 26 gold-plated phosphor bronze male contacts for excellent conductivity.
- Constructed with liquid crystal polymer housing for durability and thermal stability.
- Designed as unshrouded with straight orientation suitable for surface mount application.
- Supports a maximum voltage of 475 V and current rating of 4 A.
- Operates reliably within temperature range from -55°C to 125°C.
- Includes a mating pin length of 5.84 mm to ensure secure connection.
- Termination type is solder, suitable for mixed technology surface mounting.
- Connector system is board-to-board with surface mount type for PCB integration.
Product Description
Samtec TSM-113-01-L-DV straight surface pin header is a high-quality PCB connector featuring 26 male contacts arranged in 2 rows with a 2.54 mm pitch. This unshrouded header is designed for surface mount applications, using liquid crystal polymer housing for excellent durability and thermal performance across a broad temperature range from -55°C up to 125°C.
The phosphor bronze contacts with gold plating provide superior electrical conductivity and corrosion resistance, suitable for demanding electronic environments. The connector supports a maximum operating voltage of 475 V and a current rating of 4 A, ideal for reliable board-to-board signal and power connections in industrial, telecommunications, and electronic manufacturing applications.
Its straight orientation and solder termination type accommodate mixed-technology PCB assembly processes. The mating pin length of 5.84 mm ensures secure and consistent connections with compatible Samtec sockets, with special design features tailored to facilitate processing during board assembly.
This header is intended for electronic component manufacturers, industrial automation systems, and laboratory instrumentation requiring compact and dependable PCB connectors. Features 26 gold-plated phosphor bronze male contacts for excellent conductivity.
Constructed with liquid crystal polymer housing for durability and thermal stability. Designed as unshrouded with straight orientation suitable for surface mount application. Supports a maximum voltage of 475 V and current rating of 4 A.
Operates reliably within temperature range from -55°C to 125°C. Includes a mating pin length of 5.84 mm to ensure secure connection. Termination type is solder, suitable for mixed technology surface mounting. Connector system is board-to-board with surface mount type for PCB integration.
Row pitch and contact pitch are 2.54 mm for standard spacing compatibility. Special design facilitates processing with options for different post heights. Explore our comprehensive selection of PCB headers and connectors at EnvMart to support your electronic assembly and manufacturing needs.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This pin header supports a maximum voltage of 475 V and a current rating of 4 A.
It operates reliably within a temperature range from -55°C to 125°C.
The termination type is solder, suitable for mixed technology surface mounting.
This model features 26 gold-plated phosphor bronze male contacts.
The contact pitch is 2.54 mm, which is standard spacing for compatibility.
The housing is constructed from liquid crystal polymer, providing durability and thermal stability.
The mating pin length is 5.84 mm, ensuring a secure connection.
This pin header is designed as unshrouded, suitable for surface mount applications.
The connector system is board-to-board, designed for surface mount integration on PCBs.
It is designed specifically for surface mount applications with options to facilitate processing.
The country of origin for this pin header is India.
It is suitable for board-to-board signal and power connections in industrial, telecommunications, and electronic manufacturing applications.
