Samtec TFM Series Straight Through Hole PCB Header 30 Contacts 1.27 mm Pitch 2 Row Shrouded TFM-115-32-S-D-A

Samtec TFM-115-32-S-D-A is a rugged PCB header designed for through-hole mounting applications in electronics and electrical systems. This product is part of the TFM series, featuring 30 male contacts arranged in 2 rows with a 1.27 mm pitch. It is shrouded and straight-oriented, providing mechanical protection and blind mating capability that increases connection reliability and ease of assembly.

The housing is made of Liquid Crystal Polymer, which offers excellent mechanical strength and thermal stability, capable of operating between -55°C and 125°C. Each contact is crafted from phosphor bronze and plated with gold to ensure high conductivity, corrosion resistance, and extended product life.

This header supports up to 3.2A current and 250V voltage rating, suitable for various industrial, manufacturing, and communication equipment applications. Its termination type is solder, enabling secure attachment to printed circuit boards. The male contact design with a .018” diameter post allows optimized mating with corresponding Tiger Eye™ contact sockets and cable assemblies, making it ideal for high reliability and high cycle operations.

Additional features of this header include the availability of screw down, weld tab, and solder nail options for rugged environments and specialized mounting needs. These options support diverse design requirements in industrial automation, telecommunication, instrumentation, and other demanding electronics sectors.

Manufactured in the United States, the TFM series headers comply with robust industrial standards to ensure long-term reliability and ease of maintenance in PCB assembly processes.

This PCB header supports a current rating of 3.2A for robust electrical performance. Constructed with Liquid Crystal Polymer housing for durability and thermal resilience. Features gold-plated phosphor bronze contacts for enhanced conductivity and corrosion resistance.

Designed with a straight orientation and shrouded body for blind mating applications. Suitable for operating temperatures ranging from -55°C to 125°C, ensuring broad environmental tolerance. Compatible with wire-to-board connector systems and supports solder termination.

Provides high reliability using Tiger Eye™ multi-finger BeCu contacts suitable for high cycle applications. Contact system diameter post measures .018" (0.46 mm), optimizing connection integrity. Explore the comprehensive range of PCB Headers and connectors available in EnvMart to find solutions tailored for your industrial electronics needs.
