Samtec TSM Series Straight Surface Pin Header 20 Contacts 2.54 mm Pitch 2 Row Unshrouded TSM-110-02-S-DV
Specifications
| Country of Origin | United States |
|---|---|
| Voltage | 475V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 4A |
| Model | TSM-110-02-S-DV |
| Mount Type | Surface |
| Special Features | Designed specifically for surface mount applications with many options to facilitate processing |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | TSM |
| Termination | Surface mount, mixed technology |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 20 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Mating Pin Length | 8.13mm |
| Contact System | .025" (0.635 mm) square post |
Key Features
- The connector features a straight orientation with unshrouded design.
- Constructed using liquid crystal polymer housing for durability.
- Contacts are made of phosphor bronze with gold plating for reliable conductivity.
- Supports a maximum operating temperature of 125°C and minimum of -55°C.
- Designed for PCB board-to-board connection with surface mount termination.
- Rated for 475 V and 4 A current capacity.
- Mating pin length is 8.13 mm for secure connections.
- Specially optimized for surface mount processing and mixed technology termination.
Product Description
Samtec TSM-110-02-S-DV is a high-quality pin header designed for reliable board-to-board connections in electronic components. Featuring 20 contacts arranged in 2 rows with a 2.54 mm pitch, this straight, unshrouded surface pin header is engineered for surface mount technology (SMT) applications.
Its housing is made from durable liquid crystal polymer, ensuring mechanical stability and heat resistance. The phosphor bronze contacts are plated with gold to guarantee low contact resistance and corrosion resistance. Rated for up to 475 V and 4 A current, the connector supports a wide operating temperature range from -55°C to 125°C, suitable for demanding industrial environments.
The termination type is solder surface mount, compatible with mixed technology PCB assembly processes. The mating pin length of 8.13 mm provides secure and stable connections with compatible Samtec sockets or connectors.
This connector series offers standard post heights to accommodate various socket requirements and facilitate ease of processing during assembly. The unshrouded design allows for easy visual and mechanical access during mating. It is ideally suited for applications in industrial automation, telecommunications, consumer electronics, and laboratory equipment.
The connector consists of 20 male contacts arranged in 2 rows with a 2.54 mm pitch. Constructed with liquid crystal polymer housing and gold-plated phosphor bronze contacts. Supports operating temperatures from -55°C to 125°C and voltages up to 475 V.
Designed for surface mount solder termination with mixed technology compatibility. Ensures robust board-to-board connection for industrial and electronic manufacturing. Provides standard post heights for compatibility with Samtec sockets.
The mating pin length of 8.13 mm supports stable and reliable connections. Explore the Electronics Components category on EnvMart for more PCB connectors and headers from leading brands.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating for this pin header is 475 V.
This model has a current capacity of 4 A.
The contacts are arranged with a pitch size of 2.54 mm.
It supports an operating temperature range from -55°C to 125°C.
The housing is made from liquid crystal polymer, and the contacts are made of phosphor bronze with gold plating.
The mating pin length is 8.13 mm, providing secure connections.
This model features 20 male contacts arranged in 2 rows.
It uses surface mount termination with solder for mixed technology compatibility.
Yes, it is specifically designed for surface mount applications.
The connector has a straight orientation and is unshrouded.
It is suitable for applications in industrial automation, telecommunications, consumer electronics, and laboratory equipment.
