Samtec TSM Series Straight Surface Pin Header 10 Contacts 2.54 mm Pitch 1 Row Unshrouded TSM-110-01-T-SV
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 475V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 4A |
| Model | TSM-110-01-T-SV |
| Mount Type | Surface |
| Special Features | Designed specifically for surface mount applications with many options to facilitate processing |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | TSM |
| Termination | Surface mount, mixed technology |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 10 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Mating Pin Length | 5.84mm |
| Contact System | .025" (0.635 mm) square post |
Key Features
- Constructed with phosphor bronze contacts plated in tin for excellent conductivity.
- Housing made of liquid crystal polymer ensures durability and thermal stability.
- Rated for 4A current with a maximum operating voltage of 475V.
- Operates efficiently within a temperature range of -55°C to 105°C.
- Designed for surface mount solder termination with a mating pin length of 5.84 mm.
- Unshrouded single-row layout allows easy access for connections in dense PCB assemblies.
- Square post style offers secure insertion and stable engagement in compatible sockets.
- Specialized for surface mount applications facilitating smooth processing and assembly.
Product Description
Samtec TSM-110-01-T-SV is a premium quality, new condition straight surface pin header designed for PCB board-to-board connectors featuring 10 male contacts arranged in a single row with a 2.54 mm pitch. This pin header offers a current rating of 4A and maximum operating voltage of 475V, ensuring reliable electrical performance in demanding industrial and electronic applications.
The housing is manufactured from liquid crystal polymer, providing enhanced durability and excellent thermal resistance. The phosphor bronze contacts are tin-plated to ensure optimal conductivity and resistance to corrosion. Designed specifically for surface mount technology, it allows for efficient soldering and mixed technology terminations, making it ideal for automated processing environments.
The pin header functions effectively within operating temperature ranges from -55°C up to 105°C, making it suitable for a broad spectrum of industrial conditions. The unshrouded design with a mating pin length of 5.84 mm and .025 inch (0.635 mm) square post structure provides secure and stable engagement with compatible Samtec sockets and connectors.
This component is widely used in sectors including electronics manufacturing, industrial machinery, and telecommunications where dependable pin header connectors are essential for high-density PCB assemblies.
Constructed with phosphor bronze contacts plated in tin for electrical reliability. Liquid crystal polymer housing enhances mechanical strength and heat resistance. Supports up to 4A current and 475V voltage to meet rigorous electrical demands.
Temperature rating from -55°C to 105°C for versatile application environments. Designed for straightforward surface mount soldering and mixed technology processes. Unshrouded single-row with 10 contacts at 2.54 mm pitch for compact PCB layouts.
The Samtec TSM series is engineered to provide superior performance in electronic connectors, offering multiple post height options for flexibility in mating with various Samtec sockets. This product supports precision electronic assemblies in industrial, laboratory, telecommunications, and HVAC fields.
