Samtec Pin Header 2 Contacts 2.54 mm Pitch 1 Row Unshrouded Through Hole Termination TSW-102-08-F-S

Samtec TSW-102-08-F-S pin header is a high-quality, straight orientation connector designed for board-to-board interfacing using through-hole mounting. This robust electronic component features 2 gold-plated male contacts with a 2.54 mm pitch arranged in a single row, providing reliable electrical connections in various PCB assembly applications.

The housing is made from durable polybutylene terephthalate, offering good electrical insulation and mechanical strength to withstand industrial environments. It supports continuous current up to 4.3 A and can operate safely at voltages up to 550 V, making it suitable for many electronics manufacturing, communications, and industrial control systems.

Operating over a wide temperature range from -55°C to 125°C, this pin header performs consistently even under demanding thermal conditions. The solder termination with a 5.08 mm tail pin length ensures secure solder joints, while the 5.84 mm mating pin length provides stable connectivity with counterpart connectors.

The unshrouded, straight-through hole design simplifies installation and inspection on PCBs. Special manufacturing options available in the TSW series include various plating and ruggedizing features for cost and performance optimization.

This pin header is widely used in industrial, commercial electronics, and laboratory equipment where precise, durable interconnections are essential. It is compliant with industry standards but does not carry specific certifications.

This pin header features 1 row of male contacts for through-hole mounting. Contacts are made of phosphor bronze with gold plating ensuring durability and conductivity. Housing is constructed from polybutylene terephthalate for electrical insulation and mechanical support.

The connector supports 4.3 amps current and 550 volts voltage rating for robust applications. Operating temperature ranges from -55°C to 125°C for versatile environmental use. The contact terminations are solder type with tail pin length of 5.08 mm and mating pin length of 5.84 mm.

The unshrouded design facilitates easy soldering and installation into PCBs. Explore more electronic components and PCB connectors in our extensive Samtec offerings at EnvMart.
