Samtec Pin Header Board-to-Board 2 Contacts 2.54mm Pitch Straight Surface Mount Unshrouded TSM-102-01-L-SH
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 475V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 4A |
| Model | TSM-102-01-L-SH |
| Mount Type | Surface |
| Special Features | Designed specifically for surface mount applications with many options to facilitate processing |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | TSM |
| Termination | Surface mount, mixed technology |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 2 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 4.57mm |
| Mating Pin Length | 5.84mm |
| Contact System | .025" (0.635 mm) square post |
Key Features
- Constructed with phosphor bronze contacts plated in gold for reliable conductivity.
- Housing made from liquid crystal polymer ensures durability under thermal stress.
- Designed for board-to-board connector systems with 1 row and unshrouded male contacts.
- Operates between -55°C and 125°C, supporting up to 475 V and 4 A current.
- Tail pin length is 4.57 mm and mating pin length is 5.84 mm for secure connections.
- Specially designed to facilitate surface mount and mixed technology processing.
- Vertical orientation with straight pins suitable for precise PCB applications.
Product Description
Samtec TSM-102-01-L-SH is a high-quality pin header designed for electronic and electrical applications requiring reliable board-to-board connections. This model features a 2-contact configuration arranged in a single row with a pitch of 2.54 mm.
The pin header is optimized for surface mount technology, providing excellent performance in PCB assemblies with a straight orientation and unshrouded male contacts. It supports electrical ratings of up to 475 V voltage and 4 A current, making it suitable for diverse industrial, laboratory, and commercial electronic systems.
Operating temperature ranges from -55°C to 125°C, ensuring robust performance under various environmental conditions. The tail pin length of 4.57 mm and mating pin length of 5.84 mm enable secure and precise board connections, suitable for specialized industrial manufacturing and electronic component integration.
This pin header is designed specifically to complement Samtec sockets with a contact system featuring a .025" (0.635 mm) square post, maximizing mechanical reliability and electrical performance.
Ideal for use in industrial electronics manufacturing, automation systems, and precision electrical assemblies, this connector ensures consistent connectivity and durability across demanding applications.
Constructed with phosphor bronze contacts plated in gold for reliable conductivity. Durable liquid crystal polymer housing withstands thermal and mechanical stress. Facilitates board-to-board connections in electronic components.
Operates safely from -55°C to 125°C with high voltage and current ratings. Tail and mating pin lengths engineered for secure solder termination. Unshrouded and straight orientation for versatile surface mount applications.
Supports industrial, commercial, and laboratory electronic system assemblies. Explore more high-quality PCB Headers and connectors in the Electronics & Electricals category at EnvMart.
