Samtec TSM Series Straight Surface Mount Pin Header 10 Contacts 2 Row 2.54 mm Pitch Unshrouded TSM-105-01-L-DV-P-TR

Free Delivery in India | Lowest Global Shipping Charges

Samtec TSM Series Straight Surface Mount Pin Header 10 Contacts 2 Row 2.54 mm Pitch Unshrouded TSM-105-01-L-DV-P-TR

Name: Samtec TSM Series Straight Surface Mount Pin Header 10 Contacts 2 Row 2.54 mm Pitch Unshrouded TSM-105-01-L-DV-P-TR
Brand: Samtec
SKU: 154368
Price: 1.17 USD
Availability: InStock



Category PCB Headers Brand Samtec Condition New

Specifications

Country of Origin	United States
Voltage	475V
Brand	Samtec
Orientation	Straight
Current	4A
Model	TSM-105-01-L-DV-P-TR
Mount Type	Surface
Special Features	Designed specifically for surface mount applications with many options to facilitate processing
Housing Material	Liquid Crystal Polymer
Contact Material	Phosphor Bronze
Series	TSM
Termination	Surface mount, mixed technology
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	10
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Wire-to-Board
Tail Pin Length	1.27mm
Mating Pin Length	5.84mm
Contact System	.025" (0.635 mm) square post

Key Features

Compact 2-row configuration ideal for surface mount applications.
Gold-plated phosphor bronze contacts ensure excellent conductivity and durability.
Liquid Crystal Polymer housing material provides high mechanical strength.
Rated for 4A current and up to 475V operating voltage.
Operates reliably in temperatures ranging from -55°C to 125°C.
Designed for wire-to-board connections with solder termination.
Male contact gender with a 1.27 mm tail pin length and 5.84 mm mating pin length.
Unshrouded connector system allows easy assembly and maintenance.

Product Description

Samtec TSM-105-01-L-DV-P-TR is a premium quality straight surface mount pin header featuring 10 male contacts arranged in 2 rows with a 2.54 mm pitch, tailor-made for reliable wire-to-board connections in electronic and industrial applications.

The housing is constructed from high-strength Liquid Crystal Polymer, offering durability and excellent thermal resistance between -55°C to 125°C. Contacts are made from phosphor bronze and plated with gold to ensure superior electrical conductivity and corrosion resistance, suitable for currents up to 4A and voltages as high as 475V.

Designed specifically for surface mount technology, this pin header supports solder termination and incorporates a 1.27 mm tail pin length with mating pins measuring 5.84 mm, facilitating secure and stable connections. The unshrouded design provides effortless access during assembly and maintenance.

This TSM series pin header is an Extended Life Product™, proven to withstand harsh environments with up to 2500 mating cycles and 10 years of Mixed Flowing Gas testing, ensuring long-term operational reliability.

Compact and versatile 2-row configuration with 10 contacts. Gold-plated phosphor bronze contacts optimize performance and lifespan. Robust Liquid Crystal Polymer housing for mechanical stability and thermal endurance. Surface mount solder termination suitable for PCB assembly processes.

Wide operating temperature range from -55°C to 125°C. Rated for 4A current and 475V voltage, suitable for various industrial uses. Unshrouded design allows easy access and installation. High mating cycle durability supporting demanding applications.

Manufactured in the United States to strict quality standards.

This pin header is ideal for use in electronics manufacturing, industrial control systems, communication equipment, and other applications requiring high-reliability PCB connectors. Suitable for environments ranging from commercial electronics to harsh industrial conditions.

Explore more high-quality connectors in the PCB Headers category at EnvMart for your electronic assembly needs.
